How to Install and Set Up Your Hikvision CCTV Kit in 6 Simple Steps

Got a shiny new Hikvision CCTV kit from WME? Excellent choice. Whether you’re a first-time DIYer or an experienced installer looking to streamline your setup, Hikvision makes it easier than ever to build a smart, reliable, and professional security system.

In this guide, we’ll walk you through the six key steps to get your Hikvision cameras installed, wired, and running, without the hassle. You’ll also get extra tips on equipment, positioning, and using the Hik-Connect app like a pro.

📹 Step 1: Pick Your Hikvision CCTV Camera

The first, and most important step is to choose a CCTV camera which is right for you. Take a look at our top selling cameras below to get you started.

1. HikVision: DS-2CD2366G2-IU(2.8MM)(C), 6MP Fixed Lens Turret Camera, IR Night Vision, 3200 x 1800 Resolution, Built-in Mic, IP67

2. HikVision: DS-2SE4C425MWG-E/26(F0), TandemVu 4 MP Speed Dome, 25× Zoom, Night Vision, 12V DC & PoE+

3. HikVision: DS-2CD2346G2-IU(2.8mm)(C), 4MP AcuSense Turret Camera, 2.8mm Fixed Lens, Built-in Mic, IP67, Infrared Night Vision

🛠 Step 2: Plan Your Camera Locations Carefully

Once you've picked your camera, and before you drill a single hole, take a walk around your property. Good planning is everything when it comes to CCTV. You want to maximise coverage, avoid blind spots, and keep cabling neat and accessible.

Key areas to cover:
✅ Front and back doors (most common entry points)

✅ Driveways, side gates, and garages

✅ Rear gardens and alleyways

✅ Business access points and loading bays

✅ Shared walkways or communal entrances (where legally allowed)

🔧 Installer tip: Mount cameras around 8-10 feet from the ground. This height gives you the best balance between wide visibility and tamper resistance.

Also consider:

• Avoid placing cameras facing direct sunlight or reflective surfaces
• Use turret or dome cameras under eaves for weather protection
• Angle lenses away from windows to prevent glare at night

🔩 Step 3: Mount the Cameras Securely

Once you’ve planned your layout, it’s time to get the cameras on the wall. Hikvision kits typically include mounting plates, screws, and wall plugs - just make sure you’re using the right fixings for your wall type (brick, render, plasterboard, etc.).

Mounting checklist:

📍 Mark and drill pilot holes for wall plugs

🔧 Use the right drill bit for your surface (masonry vs wood)

🔒 Fit mounting plates and fasten the camera body firmly

🎯 Adjust the lens angle before securing fully

💡 Pro tip: Temporarily connect the camera to a monitor during installation so you can check the live view and adjust positioning on the spot.



🔌 Step 4: Run the Cables (for Wired PoE Kits)

If you’re installing a PoE (Power over Ethernet) system, each camera will connect to the NVR via a single Ethernet cable, supplying both power and data. This reduces clutter and is much easier to manage than traditional analogue systems.

Steps for clean cable runs:
🧰 Use Cat6 cables for optimal performance and future-proofing

🔧 Route cables through loft spaces, internal walls or conduit

📦 Use junction boxes and trunking for a clean finish

⚡ Connect camera ends to the NVR PoE ports (usually labelled)

🔌 Need accessories?

WME’s Wiring Accessories category has all the Cat6 cables, glands, grommets and fixings you need for a professional finish.

For outdoor runs, make sure you’re using weatherproof-rated cables or conduits, and apply silicone around entry points to prevent water ingress.

🖥 Step 5: Connect the NVR and Monitor

Once your cameras are in place and cabled, it’s time to power everything up.

NVR setup steps:
🔌 Connect all camera Ethernet leads to the back of your NVR

🖥 Use an HDMI cable to connect the NVR to a monitor or TV

🔋 Plug the NVR into the mains and switch it on

💾 Install the hard drive if it isn’t pre-installed (most WME kits include 1–2 TB)

Follow the on-screen wizard to:

• Set a secure admin password
• Select recording options (motion-activated, 24/7, schedules)
• Name your camera channels (e.g., “Front Drive”, “Back Garden”)

📹 For businesses or multi-camera homes, you can also add a backup system via USB or cloud upload for redundancy.

📱 Step 6: Set Up the Hik-Connect App for Remote Access

With your cameras live and recording, the final step is to connect them to your smartphone. The Hik-Connect app is free and allows you to view live footage, receive alerts, and replay recordings from anywhere in the world.

How to set it up:
📲 Download Hik-Connect from your app store

🧾 Register for a free Hikvision account

📸 Scan the QR code on your NVR (under "Platform Access")

🔐 Set a strong password for remote access

🔔 Enable motion alerts, mobile notifications, and auto-updates

🔧 Security note: Always change default passwords and enable two-factor authentication for added protection.

🙋 FAQs: Common Questions About Hikvision Setup

Q: How long does installation take?

A standard 4-camera wired system takes around 2–4 hours. Wireless kits are typically quicker, especially in smaller properties.

Q: Do I need a hard drive for recording?

Yes. Unless you’re using cloud storage, your system needs an internal hard drive (usually included with WME kits) to store footage.

Q: Can I set recording schedules or just record motion?

Yes, you can choose continuous, motion-only, or custom time blocks. These are configured in the NVR menu or via the app.

Q: Is this legal to install at home or business?

Yes, but make sure to follow gov.uk CCTV guidance to respect privacy laws and signage rules.

Boost Your Setup

🛒 Shop the full CCTV & Security range for kits, NVRs, cameras and monitors

🧰 Grab tools, glands and cabling from our Wiring Accessories category

🧠 Explore Smart Home Solutions to connect your cameras with lighting, sensors, or alarms

Installing a Hikvision CCTV system may sound technical - but with the right planning, a quality kit, and the Hik-Connect app, it’s something anyone can do with confidence.

Whether you're safeguarding your home, securing your business, or installing for a client, WME has everything you need, from trusted Hikvision hardware and software to professional-grade wiring accessories.
