Ruijie Products

Ruijie networking here, much of it sold under the Reyee name, covers unmanaged, cloud-managed and Layer-3 switches, business routers and home mesh Wi-Fi, indoor and outdoor Wi-Fi 6 and Wi-Fi 7 access points, outdoor wireless bridges, SFP transceivers and optical cables, PoE injectors, power modules and RG-OCE network management licences, with products aimed at homes, small offices, CCTV networks and campus sites.

Choosing Ruijie Products

Plan the network from the edge back: the access points and router first, then the switches that feed them, then the links between buildings.

Switches

Unmanaged switches such as the RG-ES108GD are plug and play, with self-adaptive ports in a metal case. Cloud-managed switches add remote control: the RG-ES205GC-P has 4 PoE/PoE+ ports and lifetime management through Ruijie Cloud, and the RG-NBS3100-8GT2SFP-P has 8 gigabit PoE ports with 2 SFP uplinks. For aggregation or a campus core, the RG-CS85-48SFP4XS-D has 48 × 1Gb SFP service ports, four 1G/10G SFP+ uplinks and Layer-3 routing including OSPF and BGP. The RG-NIS2100-8GT2SFP-HP is an industrial, fanless DIN-rail PoE switch with an IP40 rating.

Routers and Wi-Fi

The RG-EG305GH-P-E business router gives a maximum throughput of 1.5 Gbps, PoE and cloud remote management, and the RG-EG209GS adds a Gigabit SFP port. For homes, the RG-EW3200GX-PRO is a Wi-Fi 6 mesh router using Reyee Mesh, and the RG-M18 comes as a 2-pack. Access points include the RG-RAP2260(G) Wi-Fi 6 ceiling model, the RG-RAP1260 wall-plate model and outdoor units such as the IP68 RG-RAP6260(G).

Bridges and fibre

Outdoor bridges link buildings or remote cameras without a cable: the RG-EST350G is a pre-paired 5 GHz kit for links up to ~5 km line-of-sight, and the RG-AirMetro460G has a 23 dBi antenna for PTP up to 15 km LOS. SFP modules carry fibre links, such as the MINI-GBIC-LX-SM1310 at 1310 nm over single-mode fibre and the XG-SFP-LR-SM1310 at 10Gb/s.

ProductModelDetail
Unmanaged switchRG-ES108GD8-port gigabit, metal case
Cloud PoE switchRG-ES205GC-P4 PoE/PoE+ ports, Ruijie Cloud
Layer-3 core switchRG-CS85-48SFP4XS-D48 × 1Gb SFP, 4 × SFP+
Business routerRG-EG305GH-P-E1.5 Gbps, PoE
Mesh routerRG-EW3200GX-PROWi-Fi 6, Reyee Mesh
Ceiling access pointRG-RAP2260(G)Wi-Fi 6 AX1800
Outdoor access pointRG-RAP6260(G)IP68, PoE in
Wireless bridgeRG-EST350G5 GHz, pre-paired kit
SFP moduleMINI-GBIC-LX-SM13101310 nm, single-mode

Related categories

Browse Ruijie switches, Ruijie routers, Ruijie access points and Ruijie optical cable, compare makers in network switches and PoE solutions and the wider data and networking range, or read our Help & Support guides.

Frequently asked questions

What is Ruijie Cloud management?

It is the app and cloud service used to set up and manage Ruijie devices remotely. The RG-NBS5200-24GT4XS switch has lifetime management on Ruijie Cloud, the RG-RAP2260(G) access point sets up through the Ruijie Cloud app, and even the unmanaged RG-ES126FGS-P is visible on Ruijie Cloud. For an on-premises alternative, RG-OCE Network Manager licences such as the RG-OCE-NETWORK-BASE run as an on-premises management platform.

Which Ruijie switch suits an IP camera network?

A PoE switch with enough ports and power for the cameras. The RG-ES205GC-P is a small cloud-managed switch with 4 PoE/PoE+ ports aimed at CCTV networks, the RG-NBS3100-8GT2SFP-P adds 8 PoE ports and 2 SFP uplinks, and the RG-NIS2100-8GT2SFP-HP is an industrial DIN-rail model whose port 1 supports IEEE 802.3bt (PoE++) for power-hungry cameras.

How can I link two buildings without running a cable?

Use a pair of outdoor wireless bridge units. The RG-EST350G is a factory-paired 5 GHz kit for point-to-point or point-to-multipoint links, the RG-EST100-E is a pre-paired 2.4 GHz kit whose port 1 supplies 12 V passive PoE to a remote camera, and the RG-AirMetro460G is a 5 GHz CPE with a 23 dBi antenna for longer links.

Which SFP module do I need for a fibre link?

Match the module to the fibre type, speed and distance. The MINI-GBIC-SX-MM850 works over multimode fibre at 850 nm for 550 metres, the MINI-GBIC-LX-SM1310 over single-mode fibre for 10 km, and the MINI-GBIC-ZX80-SM1550 over single-mode for 80 km. BiDi modules such as the GE-SFP-LX20-SM1310-BIDI use one fibre strand and pair with a 1550 nm transmitter at the far end.

Which Ruijie router covers a whole home with Wi-Fi?

A mesh router, which links units so a device roams between them. The RG-EW3200GX-PRO is a Wi-Fi 6 dual-band mesh router using Reyee Mesh, with five Gigabit ports and concurrent access for 64 terminals, and the RG-M18 2-pack is a Wi-Fi 6 mesh set for villas and large apartments. The RG-EW1200R is a wall-plug mesh extender for weak spots.

Are there Ruijie access points for outdoor use?

Yes, several are weatherproof. The RG-RAP6260(G) is an AX1800 Wi-Fi 6 outdoor access point rated IP68 and operating from -40 to 65°C, and the RG-RAP52-OD is an AC1300 Wi-Fi 5 outdoor model in an IP65 enclosure with PoE power and removable antennas. The RG-RAP6260(G) suits hospitality, education and retail uses, and the RG-RAP52-OD villa, retail and small-site coverage.
