Mixers

A mixer blends microphones, instruments and playback sources into one balanced signal for the speakers, an amplifier or a recording. This range covers compact and live mixing consoles, powered mixers with a built-in amplifier, DJ mixers with phono inputs, rack mixers and zone mixers for installed sound, and a mini microphone mixer that runs on a battery, mainly from Citronic and Adastra.

Choosing Mixers

Start with the job: live mixing for a band or event, DJ mixing, or a fixed installation that routes sources to zones.

Live and portable mixers

Count the microphones, instruments and players, then add a spare channel or two. The Citronic Q-PAD 170.814UK has 2 mono channels and doubles as a USB audio interface, the CMA-series 170.864UK has 4 mono and 2 stereo inputs with 99 DSP effects, and the CSX-18 170.885UK console takes 14 mono mic/line inputs. The CSR-63 170.809UK fits a rack with 6 mic/line and 3 stereo channels.

Powered mixers

A powered mixer has a stereo amplifier built in, so passive speakers connect directly. The Citronic CSP 170.841UK is rated 200W with 8 inputs, the 170.845UK 2 x 350W with 14 inputs, and the FLITE-600 170.600UK packs 2 x 300W, two UHF microphones and DSP effects into a moulded flight case.

DJ mixers

The Citronic PRO-2 MKII 172.752UK is a two-channel DJ mixer with 2 phono, 2 line and 1 mic input, and the 172.776UK is a 4-channel 19in mixer with 14 inputs, USB in/out and three mic inputs for karaoke.

Installed and zone mixers

For fixed systems, the Adastra 953.024UK is a 1U rack mixer with 4 mic inputs and paging priority, and the RX45 953.046UK matrix feeds 4 inputs to 5 stereo zones, expandable to 40 zones with 8 units. The Clever Acoustics CRAM34 routes 5 inputs to 4 zones for external amplifiers.

TypeExampleInputsNotes
Mini microphone mixerQTX 170.202UK4 mic9V battery or 12Vdc adaptor
Compact mixerCitronic 170.866UK6 mono, 2 stereoUSB, Bluetooth, 99 DSP effects
Live consoleCitronic CSX-18 170.885UK14 mono, 2 stereo7-band graphic EQ
Powered mixerCitronic CSP 170.843UK102 x 200W
DJ mixerCitronic 172.776UK14, 4 channelsUSB in/out
Zoning mixerAdastra 953.019UK2, to 5 zonesBalanced XLR

Brands we stock in audio mixers

Citronic, Adastra, Clever Acoustics, Bose Professional and QTX. Citronic and Adastra make most of the mixers here, Adastra with rack and zone mixers for installed sound.

Related categories

Send the mix to power amplifiers and PA speakers and systems, wire it up with XLR and Speakon connectors, or see mixer amplifiers for a mixer and amplifier in one box. Our Help & Support guides explain channel counts and routing.

Frequently asked questions

What is the difference between a powered and an unpowered mixer?

A powered mixer has an amplifier built in and drives passive speakers directly, while an unpowered mixer sends a line-level signal on to active speakers or a separate power amplifier. The Citronic CSP 170.843UK, for example, is a powered mixer with an internal stereo power amplifier rated 2 x 200W and balanced main outputs.

How many channels does a mixer need?

Enough channels for the microphones, instruments and playback sources connected at once, plus a spare channel or two. A duo with two vocals and a guitar fits the Citronic CMA-series 170.862UK with 2 mono and 2 stereo inputs, while a band that mics its drums needs a console such as the CSX-18 170.885UK, with 14 mono mic/line inputs.

Which mixers provide phantom power for condenser microphones?

Mixers listing +48V phantom power include the Citronic CSR-63 170.809UK, Q-PAD 170.814UK, CMA-series 170.864UK and CSX-18 170.885UK, and the CSP powered mixers list 48V on their XLR inputs. The Adastra 953.024UK and 953.028UK installed mixers provide +20V. Dynamic microphones work without phantom power.

Can a mix be recorded on a computer?

Yes. The Citronic Q-PAD 170.814UK works as a USB audio interface for recording and playback on a PC, powered through its USB Type-C port, and the CMA-series 170.864UK and 170.866UK have USB audio play and record. The CSX-18 170.885UK has a built-in USB media player for playback and for recording the mix.

What should I look for in a DJ mixer?

Look for enough channels for your decks and players, phono inputs for turntables, a crossfader and headphone cue. The Citronic PRO-2 MKII 172.752UK has 2 channels with 2 phono, 2 line and 1 mic input, and the 172.776UK has 4 channels, 14 inputs, a replaceable 45mm crossfader and USB in/out for playback or recording.

What is a zone mixer?

A zone mixer routes several audio sources to separate areas of a building, with a source and level choice per zone, and feeds external amplifiers. The Clever Acoustics CRAM34 has 5 inputs and 4 output zones, the Adastra 953.019UK sends 2 inputs to 5 stereo zones over balanced XLR, and the RX45 953.046UK matrix adds a USB, DAB+ and Bluetooth player.

Can music be played to a mixer from a phone?

Yes, through a mixer with a Bluetooth receiver. The Citronic CSR-63 170.809UK, CMA-series 170.864UK, CSX-18 170.885UK and FLITE-600 170.600UK have Bluetooth, and the Adastra 953.028UK rack mixer combines Bluetooth with a USB player and FM tuner for background music and public address in installed systems.

Is there a small mixer for a few microphones?

Yes. The QTX 170.202UK mini microphone mixer is a compact mono mixer with low-impedance jack inputs, a separate volume control per microphone and a master output on a 6.3mm jack. It runs on a 9V battery or an optional 12Vdc adaptor, so it suits a lectern, a small meeting or a portable recording setup.

What are the Clever Acoustics wall plates for?

They are remote plates for the Clever Acoustics ZM 8 zone mixer (CRAM19), connected by a single CAT5e cable and powered at 24V DC from the controller. The CRAM19A adds source selection, volume and local line and mic inputs, the CRAM19B source and volume control, and the CRAM19C two remote microphone inputs with tone controls.
