Smart Home Accessories

Smart home accessories on this page include Ajax WaterStop valves, wireless shut-off valves that join an Ajax hub, and most of them shut off the water supply on a leak alarm or through automation scenarios. They pair a motorised or electric actuator with a RuB brass valve, come in DN15 (1/2"), DN20 (3/4") and DN25 (1") sizes, and take an optional external supply. The page also carries Ajax keypads, relays and replacement housings.

Choosing Smart Home Accessories

Choose the valve by the pipe it will sit on, then plan how it will be powered and what will tell it to close.

Sizes and threads

The WaterStop DN15 Smart and the DN15 45643.146.BL1 fit a 1/2" line and the WaterStop 3/4" is the DN20 version with a BSPP threaded valve. The WaterStop Jeweller DN25 and the WaterStop Smart Motorised Shut-off Valve are the two 1" (DN25) valves, and the Jeweller DN25 has BSP parallel female-to-female threads.

What closes the valve

Most WaterStop valves here can close through automation scenarios as well as on a leak alarm. The DN15 Smart and DN25 Jeweller take Ajax LeaksProtect or third-party leak detectors as triggers and can be closed from the Ajax app. The DN25 Jeweller integrates with the Hub 2, Hub Plus, Hub Hybrid and ReX. Closing takes about 5 seconds on the 3/4" valve, about 5 to 7 seconds on the DN15 Smart and up to 7 seconds on the DN15 45643.146.BL1 and the two DN25 valves.

Power and battery life

Each valve runs on 4 x CR123A batteries. An external supply of 7.5 to 14 V can be added to every valve, and on the 3/4" valve and the DN15 45643.146.BL1 it turns the batteries into a backup. On the DN20 and both DN25 valves the batteries last up to about 3 years, depending on settings or use.

Local control and protection

Each valve can also be worked on site, with a lever, a button or both. The 3/4" valve adds stuck-prevention rotations and thermal and overload protection, and the 1" smart valve has an anti-tamper mounting lock and a sabotage alarm.

ValveSizeClosing timeExternal power
WaterStop DN15 Smart1/2"5–7 seconds7.5–14 V
WaterStop DN15 45643.146.BL11/2"up to 7 seconds7.5–14 V
WaterStop DN203/4"about 5 seconds7.5–14 V
WaterStop Jeweller DN251"up to 7 seconds7.5–14 V
WaterStop Smart Motorised DN251"up to 7 seconds7.5–14 V

Related categories

Pair a valve with water leak detectors and the Ajax security systems range, or see more smart home and automation, smart plugs and sockets and wireless controls. Our Help & Support guides have more advice.

Brands we stock in Smart Home Accessories

Ajax, CIE Group, EZVIZ, Ring and Videofied.

Frequently asked questions

What smart home accessories are on this page?

The smart home accessories here include Ajax WaterStop wireless shut-off valves, most of which cut the water supply when a leak is detected, as well as Ajax keypads, relays and replacement housings. The WaterStop DN15 Smart and the DN15 45643.146.BL1 suit a 1/2" line and the WaterStop 3/4" is the DN20 version with a BSPP threaded valve. The WaterStop Jeweller DN25 has BSP parallel female-to-female threads, and the WaterStop Smart Motorised Shut-off Valve is the other 1" model.

How is an Ajax WaterStop powered?

By 4 x CR123A batteries, with the option of an external supply. Every valve accepts 7.5 to 14 V. The DN20 and both DN25 valves give a battery life of up to about 3 years, and on the 3/4" valve and the DN15 45643.146.BL1 an external supply makes the batteries a backup.

How quickly does a WaterStop valve shut off the water?

In a few seconds. The 3/4" (DN20) valve has a typical closing time of about 5 seconds, the DN15 Smart closes in about 5 to 7 seconds, and the DN15 45643.146.BL1 and both DN25 valves close in up to 7 seconds. The DN25 Jeweller has a high-torque actuator of up to 8.5 N·m for reliable operation even on partially seized valves.

Can a WaterStop valve be opened or closed by hand?

Yes. The 3/4" (DN20) valve has a manual lever and an actuator button for local control, and the 1" smart valve can be worked locally by button or mechanical lever. The DN15 Smart has a manual on-device button, the DN15 45643.146.BL1 has a control button on its actuator and a lever on its mounting platform, and the DN25 Jeweller opens and closes from a local push-button. Both DN15 valves, the DN25 Jeweller and the 1" smart valve can also be controlled remotely through the Ajax app.

Can a WaterStop valve close automatically when a leak is detected?

Yes. The DN15 Smart and the DN25 Jeweller shut off automatically when Ajax LeaksProtect or a third-party leak detector triggers them, and the 1" smart valve integrates with leak detectors and automation scenarios. The 3/4" valve closes the water supply on a leak alarm and can also close on schedules and arming events. These scenarios run through an Ajax hub, which each WaterStop joins over Jeweller radio.
