Heat Detectors

Heat detectors raise a fire alarm on temperature rather than smoke, for places where smoke detectors are unsuitable. EN 54-5 sorts them into classes by how they respond, such as rate-of-rise or fixed high temperature. This page holds conventional, addressable and wireless heat detectors from brands including Apollo Fire, Hochiki, Kidde, Ajax, Comelit PAC and System Sensor, such as the Apollo RW1000-460APO, which can be set to class A1R or BS.

Choosing Heat Detectors

Choose how the detector responds to heat, how it connects to the panel, and where it will be fitted.

Fixed temperature or rate-of-rise

For the Apollo Orbis ORB-HT-11004-APO, a static heat detector responds only when a fixed temperature has been reached, while a rate-of-rise detector also has a fixed upper limit but measures the rate of increase in temperature, so a fire might be detected at an earlier stage. The Hochiki DFJ-AE3 is a 60°C fixed temperature heat detector and the DFJ-CE3 a 90°C one. The Hochiki DCD-AE3 and DCD-CE3 are rate of rise heat detectors with a 60 °C and a 90 °C fixed temperature element. The Kidde 6298 has a fixed temperature alarm level of 117°C, Class E S.

Classes and selectable modes

The Kidde KE-DT3101W-HAB supports EN54 Class A with static and rate-of-rise temperature response, as well as Class B with rate-of-rise response. The Comelit PAC 45RCS100 wireless detector detects a fixed threshold of 58°C in addition to rapid changes in temperature (rate of rise), as set out by EN 54-5 for class A1R.

Conventional, addressable or wireless

The C-TEC C4403A2 is suitable for use with virtually all known conventional fire alarm panels, with a wide 6-33V DC operating voltage and two LED indicating strips for 360° visibility. The Kidde DT2063N is an addressable heat detector certified to class A2R, with easy numeric addressing (1-128). The Apollo XPA-HT-11171-APO is wireless, with a five-year battery life using standard AA alkaline batteries. The Cygnus SN.DTH1.1 is completely wireless, with no cables required and a radio range of up to 350m.

Dirty, damp and hazardous areas

The Apollo ORB-HT-11001-APO and 55000-126APO are for environments that are dirty or smoky. The Kidde 6298 is intended for outdoor or indoor use in high humidity areas. The Hochiki ACB-EW is an IP67 waterproof multi-heat sensor that can be used externally. The Hochiki DCD-1E-IS(WHT) is an intrinsically safe heat detector for hazardous areas, and the Apollo ORB-HT-41004-MAR is approved for use in marine environments.

ModelResponseConnection
C4403A2Class A2 fixed temperatureConventional panels
DFJ-CE390°C fixed temperature–
DT2063NClass A2RAddressable
RW1000-460APOA1R or BSWireless addressable
6298117°C, Class E S–

Related categories

See the wider fire detectors range, bases in fire detector bases, and cable-based sensing in linear heat detection cable.

Brands we stock in Heat Detectors

Ajax, Apollo Fire, Bull, C-TEC, Comelit PAC, CQR, Cygnus, Dahua Technology, Eaton, EMS, FireClass, Hochiki, Kidde, System Sensor and Vimpex.

Frequently asked questions

What is a smoke and heat detector?

A smoke and heat detector, often called a multi-sensor, combines an optical smoke chamber and a heat sensor in one head. Reading the two signals together helps it pick up smouldering and flaming fires while rejecting some nuisance sources such as steam and dust. Check that the detector suits the fire alarm panel and base it will work with. The range here includes combined optical and heat multi-sensor detectors.

What is the difference between a heat detector and a smoke detector?

A heat detector triggers at a set temperature or a rapid rise, while a smoke detector responds to the smoke particles a fire gives off. Smoke detection usually gives earlier warning, so heat detectors tend to be fitted where dust, steam or fumes would cause false alarms, such as plant rooms and dusty workshops. Many fire alarm systems combine the two, placing heat detectors where smoke detection would not suit.

What is a heat detector?

A heat detector is a fire alarm device that triggers when the air around it reaches a set temperature or rises unusually quickly. Fixed-temperature types react at a threshold, while rate-of-rise types also respond to a rapid climb. They connect to a panel as conventional, addressable or wireless devices. The range here includes fixed-temperature, rate-of-rise and marine heat detectors and linear heat detection cable.
