Hikvision - Indoor Cameras

Among the Hikvision indoor cameras here, the DS-2CD2E43G2-U in-ceiling mini domes are made for retail spaces, corridors and offices. This page has AcuSense cube cameras with a PIR sensor, AcuSense in-ceiling mini domes, separated pinhole cameras for concealed installs, fisheye cameras for wide-area coverage from a single camera, a Turbo HD analogue dome, and two thermal devices, one for temperature screening at an entrance and one for presence and fall detection in care rooms.

Choosing Hikvision - Indoor Cameras

Hikvision indoor cameras include AcuSense cube and mini dome cameras, fisheye cameras and covert pinhole cameras for discreet indoor surveillance, plus thermal units for temperature screening and room presence detection.

Cube and mini dome cameras

The DS-2CD2483G2-I is an 8 MP AcuSense cube camera with a 2.8 mm lens, a PIR sensor, two-way audio and microSD up to 512 GB. The DS-2CD2446G2-I is a 4 MP AcuSense cube with a PIR range of about 8 m and two-way audio. For ceilings, the DS-2CD2E43G2-U is a 4 MP AcuSense in-ceiling mini dome with human and vehicle classification and a built-in microphone, here with a 4 mm or a 2.8 mm lens.

Pinhole and covert cameras

Separated cameras such as the DS-2CD6425G1-10 have a tiny camera head that can be recessed or hidden, with the main body mounted remotely. The DS-2CD6425G1-L20 has an L-shaped 2.8 mm pinhole head on an 8 m lead, and the DS-2CD6425G1-20 a 3.7 mm pinhole head on a 2 m cable. The DS-2CD2D25G1-D/NF is a compact zinc-alloy 2 MP pinhole camera that runs on 12 VDC.

Fisheye cameras

The DS-2CD2955FWD-IS and DS-2CD2955G0-ISU are 5 MP fisheyes with a 1.05 mm lens and a 180° field of view, for ceiling, wall or table mounting. The recessed DS-2CD63C5G1-S/RC (12 MP, 1.29 mm) and DS-2CD6365G1-S/RC (6 MP, 1.16 mm) add people counting, heatmap and queue management analytics. The DS-TCPC06-EP is a 12 MP fisheye for indoor car parks, with parking-space occupancy detection.

Analogue and thermal

The DS-2CE56D0T-IRMMF is a 2 MP Turbo HD indoor dome with switchable TVI, AHD, CVI and CVBS output for broad DVR compatibility, and Smart IR to about 20 m. The DS-2TB1217-3/QA pairs a 160 × 120 thermal module with a 4 MP visible sensor for indoor temperature screening. The HM-TD1018-1/QR combines thermal imaging with radar for presence, out-of-bed and fall detection in care rooms, using thermal imagery rather than visible video.

ModelTypeResolutionLens
DS-2CD2483G2-IAcuSense cube8 MP2.8 mm
DS-2CD2E43G2-UIn-ceiling mini dome4 MP4 mm
DS-2CD6425G1-L20Separated pinhole2 MP2.8 mm
DS-2CD2955G0-ISUFisheye5 MP1.05 mm
DS-2CD63C5G1-S/RCRecessed fisheye12 MP1.29 mm
DS-2CE56D0T-IRMMFTurbo HD dome2 MP2.8 mm

Related categories

For external coverage see Hikvision outdoor cameras, and for the whole line Hikvision CCTV cameras. Other concealed cameras are in covert and pinhole cameras and thermal models in Hikvision thermal cameras. Recording is in network video recorders, and mounts in camera mounts and brackets.

Frequently asked questions

What does an indoor fisheye camera give you?

Panoramic coverage from one unit. The DS-2CD2955G0-ISU gives full 180° panoramic coverage from a single 5 MP unit, with fisheye display modes set up in the camera web interface. The recessed DS-2CD6365G1-S/RC gives a single 360° fisheye image with several dewarping modes, and suits large indoor areas where one 360° view reduces the number of cameras required.

How do I install an indoor camera?

Mount it in a position the model is designed for and power it by PoE or 12 VDC. The DS-2CD2955G0-ISU suits ceiling, wall or tabletop mounting, and PoE simplifies its power and network cabling. The DS-2CD6365G1-S/RC is intended for recessed indoor installation, so check the mounting cut-out and clearance before fitting it. The DS-2CD2E43G2-U mini dome takes PoE or 12 VDC power, and a qualified installer should do permanent mains work.

Which Hikvision indoor camera should I choose?

Choose a cube or in-ceiling mini dome for offices and retail, a separated pinhole camera for concealed installs, or a fisheye for wide-area single-camera coverage. The DS-2CD2446G2-I cube is made for offices, retail and other indoor surveillance, and the DS-2CD2E43G2-U mini dome suits retail, corridors and offices. The DS-2CD6425G1-L20 has its pinhole sensor head on an 8 m cable for concealed installs in ceilings or fixtures, and the DS-2CD2955G0-ISU fisheye gives 180° coverage from a single unit.

What is the bi-spectrum thermographic camera used for?

Indoor temperature screening, for example at an entrance. The DS-2TB1217-3/QA pairs a 160 × 120 VOx thermal module with a 4 MP optical sensor and raises temperature-exception alarms, with a typical screening range of 30–45 °C. Accurate readings need the recommended mounting, a controlled indoor windless environment and calibration.
