Dual Relay Controller CHQ-DRC2(SCI)
IP65 Rated
£
66
60
(Incl. VAT)
RRP: £74.00
WME Care
About this product
Hochiki CHQ-DRC2(SCI) Overview
The Hochiki CHQ-DRC2(SCI) is a Dual Relay Controller expertly designed for effective control of various devices, including dampers and shutdown systems. This controller features:
- Two general-purpose relay outputs, each with independent controls.
- Local power supply fault monitoring.
- IP65 rated with optional back box (CHQ-BACKBOX).
Technical Features:
- Operates on a loop power basis with a single loop address.
- Relay contacts rated at 30 V dc and up to 1 A.
- Auxiliary monitored input and DIN rail compatibility.
Compliant with the highest safety standards (LPCB approved) for reliable performance in any environment.
-
Download
- Hochiki CHQ-DRC2SCI
Technical Details
Specifications
Model Number
CHQ-DRC2(SCI)
Operating Voltage
17 - 41 V dc
Relay Contact Rating
30 V dc max, 1 A
Operating Temperature Range
-10 °C to +50 °C
Storage Temperature Range
-30 °C to +60 °C
Maximum Humidity
95% RH Non Condensing
Dimensions
Length
157 mm
Width
127 mm
Depth
35 mm
Specifications
| Model Number | CHQ-DRC2(SCI) |
|---|---|
| Operating Voltage | 17 - 41 V dc |
| Relay Contact Rating | 30 V dc max, 1 A |
| Operating Temperature Range | -10 °C to +50 °C |
| Storage Temperature Range | -30 °C to +60 °C |
| Maximum Humidity | 95% RH Non Condensing |
Dimensions
| Length | 157 mm |
|---|---|
| Width | 127 mm |
| Depth | 35 mm |
Hochiki CHQ-DRC2(SCI) Dual Relay Controller, Addressable Fire Alarm...
From
£66.60
£74.00
Unit price
/
Unavailable
Dual Relay Controller CHQ-DRC2(SCI) features
Hochiki CHQ-DRC2(SCI) Dual Relay Controller, Addressable Fire Alarm Accessory, 30 V dc, 1 A, IP65, Hochiki CHQ-DRC2SCI
