Vanderbilt Products

Vanderbilt products here centre on door access control. The page holds 125 kHz proximity readers for ACTProx and HID-compatible tokens in mullion and compact formats and with a keypad, a pack of 10 ACT 125kHz tags, the V42 codelock with two four-digit codes, and accessories: a flush-mount plate for the MF1030PM reader, a stainless steel vandal-resistant cover for ACTpro 1030 readers, and a yo-yo card holder with a friction clip.

Choosing Vanderbilt Products

Start with the credential your users will carry, then choose the reader format that fits the door frame and the weather it faces.

Proximity readers

The EM1030e is a slim mullion reader for doorframe mounting that reads ACTProx 125 kHz and HID-compatible tokens, with Wiegand and Clock & Data outputs, a tri-colour LED, an audible tone and a 2 m pigtail lead. The EM1030e is rated IP66 and IK08 and operates from -40 °C to +70 °C. The EM1040e is a compact multiformat reader of approximately 94 × 130 × 25 mm, rated IP65 and IK10, with selectable Wiegand or Clock & Data output, surface or flush mounting and 5–12 V DC operation.

Keypad reader and codelock

The EM1050e adds an integrated keypad and can run in prox-only, PIN-only or combined PIN and prox modes, with Clock & Data or 26-bit Wiegand output and IP55 and IK08 ratings. The V42 codelock accommodates two four-digit codes, suits indoor and outdoor mounting and runs on 12 to 24 VAC, with its settings managed directly on the unit.

Tags and accessories

The EM10T3 is a pack of 10 ACT 125kHz tags, CE and UKCA certified. The MF-VR is a stainless steel vandal-resistant cover for ACTpro 1030 readers, including the MF1030, EV11030 and EM1030, and the MF-FM is a flush mount plate for mounting the MF1030PM reader. The CARD-YO is a small yo-yo card holder whose friction clip holds an ID card securely while giving a quick release.

ModelTypeCredential or entryRating
EM1030eMullion readerACTProx 125 kHz, HID-compatibleIP66, IK08
EM1040eCompact readerACTProx 125 kHz, HID-compatibleIP65, IK10
EM1050eReader with keypadProx, PIN or bothIP55, IK08
V42CodelockTwo four-digit codesIndoor or outdoor
EM10T3Tags, pack of 10ACT 125kHzCE, UKCA

Related categories

More access control equipment is in access control systems, with more fobs in proximity cards and keyfobs, keypads in keypads and readers and further fittings in access control accessories. Browse the wider security and surveillance section, and see our Help & Support blog for advice.

Frequently asked questions

Which Vanderbilt products are on this page?

They centre on access control. The EM1030e mullion reader, the EM1040e compact reader and the EM1050e keypad reader read ACTProx 125 kHz credentials and HID-compatible tokens, and the EM10T3 is a pack of 10 ACT 125kHz tags. The V42 codelock takes two four-digit codes, and the accessories are the MF-VR stainless steel cover for ACTpro 1030 readers, the MF-FM flush mount plate for the MF1030PM and the CARD-YO card holder.

Will a Vanderbilt reader connect to my existing controller?

Yes, if the controller accepts Wiegand or Clock & Data. The EM1030e offers Wiegand and Clock & Data interface options, the EM1040e has selectable Wiegand or Clock & Data outputs with a screw-terminal connector block, and the EM1050e outputs Clock & Data or 26-bit Wiegand with auto-detect. The EM1030e is wired through an approx. 2 m pigtail lead.

Can these readers be fitted outdoors?

Yes, the three proximity readers suit indoor or outdoor use. The EM1030e is rated IP66 and IK08 with potted electronics, the EM1040e IP65 and IK10, and the EM1050e IP55 and IK08. For high-risk entry points, the MF-VR stainless steel vandal-resistant cover fits ACTpro 1030 readers, and the V42 codelock suits indoor or outdoor mounting.

Can I use a PIN code instead of a card?

Yes, the EM1050e has an integrated keypad and runs in prox-only, PIN-only or combined PIN plus prox modes, so a site can use codes, cards or both together. The V42 codelock accommodates two four-digit codes for dual access, mounts indoors or outdoors and runs on 12 to 24 VAC.

What is a mullion reader?

A mullion reader is a slim reader designed for doorframe mounting. The EM1030e is a slim mullion-style multiformat proximity reader for doorframe mounting, surface or flush, with a robust polycarbonate housing and potted electronics, a tri-colour LED and an audible tone. It suits doorway frames, gates, turnstiles and internal or external entries.
