Product Overview & Key Benefits

The V-series Dual Zone 100V Mixer-Amplifier is a cutting-edge solution designed for versatility in public address systems. Perfectly suited for commercial spaces, leisure venues, and various installation scenarios, this mixer-amplifier stands out with its class-D amplifier technology, delivering reliability and high-quality sound. With the ability to operate in dual output zones, this unit allows for independent audio control, ensuring that each area receives the appropriate sound mix for events or announcements.

Among its key benefits are the seamless playback options for various audio sources including Bluetooth®, DAB+/FM radio, and USB/SD devices, making it a complete solution for any setting that requires flexible audio delivery. The comprehensive control features suit both installers and users alike, facilitating easy management of sound levels and sources.

Technical Specifications & Product Details

• Model: V-series Dual Zone 100V Mixer-Amplifier
• Power Output: 2 x 240W rms
• Audio Sources: Bluetooth, DAB+/FM, USB, SD, internal audio player
• Inputs: 3 x balanced mic/line (Jack/XLR/screw), 2 x unbalanced line (RCA), Auxiliary (RCA/3.5mm)
• Zone Outputs: 2 x terminal outputs (100V/8 Ohms/4 Ohms/COM), 2 x RCA line outputs
• Dimensions: 435 x 273 x 88 mm (without feet)
• Weight: 7.20 kg
• Power Supply: 170-264 Vac, 50Hz (IEC)
• Input Impedance: 1k Ohms (mic/line)
• Phantom Power: +20V switchable for XLR inputs
• Bluetooth Version: 5.0
• Signal-to-Noise Ratio (SNR): 84dB (line), 82dB (mic)
• Total Harmonic Distortion (THD): < 0.76% @ 1kHz
• Frequency Response: 100Hz - 20kHz
• Input Sensitivity: -11dB (line), -46dB (mic)
• Equaliser: Bass and Treble adjustment for each zone

Ideal Uses & Applications

Designed for both domestic and commercial applications, the V-series Dual Zone 100V Mixer-Amplifier is ideal for public venues such as conference centres, restaurants, educational institutions, and retail spaces. Its dual zone functionality allows for tailored audio environments; for instance, in a restaurant, one area can play background music while making announcements to an adjoining space. In schools, it can be set up for classroom activities or assemblies with ease.

Moreover, the extensive input options make it suitable for various microphones, instruments, and audio playback devices, allowing users to integrate the system into their existing setups effortlessly. Whether it is for live performances, presentations, or broadcasting messages, this mixer-amplifier provides crucial support for a wide range of scenarios.

Energy Efficiency & Cost Savings

The V-series Dual Zone 100V Mixer-Amplifier is not just about performance; it is also an eco-friendly choice. By utilising a class-D amplifier, it operates more efficiently compared to traditional amplifiers, which translates to lower energy consumption. This feature can contribute substantially to reduced electricity bills, potentially saving users up to 50 percent compared to older, less efficient audio systems.

Additionally, its high-quality construction and durable components ensure longevity, reducing the costs associated with frequent replacements. Investing in the V-series Mixer-Amplifier not only enhances audio delivery but also supports sustainable and cost-effective practices in audio management.
