TP-Link VIGI NVR2016H-16MP | 16-Channel PoE+ 4K Network Video Recorder with 140W PoE, Dual SATA, H.265+ | SKU: VID-VIGITPNVR2016H-16MP

TP-Link VIGI NVR2016H-16MP (SKU: VID-VIGITPNVR2016H-16MP) is a high-performance 16-channel PoE+ Network Video Recorder purpose-built for medium to large-scale surveillance systems. Combining 4K HDMI output, 16MP decoding, 140W PoE power budget, dual SATA interfaces, and advanced smart playback functionality, this professional-grade NVR offers unparalleled flexibility, scalability, and intelligent video management for commercial security setups.

Key Features:

• 16-Channel PoE+ Support
  Designed for scalability, the NVR2016H-16MP supports 16 IP video inputs via PoE+ (IEEE 802.3af/at) RJ-45 ports, each capable of delivering up to 30W. This eliminates the need for separate power sources at camera locations, drastically simplifying deployment and saving on cabling costs.

• Stunning 4K HDMI Output with 16MP Decoding
  Equipped with 4K HDMI and 1080p VGA outputs, this NVR can display ultra-sharp images on up to 16 channels simultaneously. With decoding capacity of 8-ch@2MP or 4-ch@8MP at 30fps, users can view and playback every critical detail from every connected camera.

• Optimised Storage with Dual SATA Bays
  With support for 2 SATA drives of up to 16TB each (32TB total), the NVR can record continuously for over 1,000 days depending on compression settings. H.265+ compression reduces bandwidth and disk usage without compromising image quality.

• Advanced Smart Detection and Alerts
  Includes an extensive suite of smart analytics such as motion detection, tampering, intrusion detection, line crossing, loitering, abandoned object alerts, and more. Anomaly alarms monitor disk status, IP conflicts, video loss, and fan exceptions to ensure uninterrupted performance.

• Flexible Recording & Playback
  Choose from manual, scheduled, or motion-triggered recording. Playback features include fast-forward, rewind, digital zoom, tag/event playback, and video export. Supports instant playback for quick footage review after an incident.

• Plug & Play with One-Click Initialization
  The system supports automatic camera addition and HDD initialization, making installation user-friendly and efficient for installers or IT administrators.

• Remote Access and Cross-Platform Compatibility
  Seamlessly monitor live or recorded footage via the VIGI app (iOS/Android), desktop client (VIGI Security Manager), or web browsers including Chrome, Firefox, Edge, and Safari. This allows complete system control from anywhere with an internet connection.

• Robust Network Protocol Support
  Interoperability is ensured with ONVIF Profile S and CGI support, enabling integration with a wide range of third-party IP cameras. Network protocols include UPnP, NTP, SMTP, HTTPS, DHCP, RTP, and more for enterprise-grade connectivity.

Example Use Case:

Ideal for retail chains, warehouses, logistics hubs, or multi-storey offices, the VIGI NVR2016H-16MP enables full 360° surveillance with PoE simplicity. For example, a distribution center can connect 16 PoE IP cameras across loading bays, aisles, and reception. All cameras stream high-definition footage to the NVR, stored securely across dual HDDs. With smart alerts for unauthorised access or anomalies, managers are immediately notified via the VIGI app, even off-site.

Technical Summary:

• Brand: TP-Link

• Model: VIGI NVR2016H-16MP

• SKU: VID-VIGITPNVR2016H-16MP

• Max Input Channels: 16 PoE+ (30W/port, 140W total)

• Max Output: 4K HDMI & 1080p VGA

• Compression: H.265+, H.265, H.264+

• Storage: 2 × SATA up to 16TB each (HDDs not included)

• Audio I/O: 1-in, 1-out (RCA) with 2-way audio

• Alarm I/O: 6 inputs, 4 outputs

• Power Supply: 53.5V DC, 3.37A

• Working Temp: -10°C to 55°C

• Warranty: 5 Years

Secure your premises with one of the most reliable and comprehensive NVRs on the market. The TP-Link VIGI NVR2016H-16MP is your professional choice for high-definition, scalable, and intelligent video surveillance.
