SHE1GEM LED Bulkhead with Emergency Function
The Sherpa range of IP65 LED bulkheads are suitable for a wide range of environments. This product features a heavy duty, robust die-cast aluminium body with a tough impact-resistant polycarbonate diffuser.
Key Features:
- Low Energy Consumption
- Low Maintenance
- Anti-Vandal Polycarbonate Diffuser and Fixings
- CCT Adjustable - 3000K, 1600lm / 4000K, 1790lm / 6000K, 1810lm
Specifications:
Class: I
Finish: Grey
IP Rating: IP65
Construction: Die-cast aluminium
Primary Voltage: 230V 50Hz
This model also includes emergency options and is suitable for high-traffic areas.
Specifications
Dimensions
Lamp
Driver
Luminaire
Photometric
Specifications
Class | I |
---|---|
Finish | Grey |
IP Rating | IP65 |
Construction | Die-cast aluminium |
Primary Voltage | 230V 50Hz |
Dimensions
Diameter | 360 mm |
---|---|
Projection | 92 mm |
Lamp
L70B50 | 50,000 |
---|---|
Dimmable | No |
Beam Angle | 110 |
Lamp Technology | SMD LED |
Energy Rating (Class) post 2021 SLR | D |
Driver
Driver Type | Constant Current |
---|
Luminaire
Diffuser | Opal |
---|---|
Emergency | Maintained / Non-maintained / Switched |
Photometric
CCT | 3000/4000/6000 K |
---|---|
CRI | >85 |
Lumens | 1680/1790/1810 lm |
Wattage | 18 |
Lumens (Em. mode) | 190/200/190 lm |
Efficacy (Light source) | 133 lm/W |
Lumens (Light source only) | 3000 lm |
SHE1GEM LED Bulkhead with Emergency Function features

18W LED Round Bulkhead with Emergency Function, CCT Adjustable, IP65, Grey Die-Cast Aluminium, 230V, 2000lm, SHE1GEM
