Adastra: 953.244UK, 100V Mixer Amplifier, 240W, 4-Zone Paging, Bluetooth, USB/SD

Product Overview & Key Benefits

The100V Mixer Amplifier with 4-zone Pagingis a powerful 240W mixer amplifier designed for versatile sound distribution across multiple zones. Ideal for applications ranging from commercial buildings to hospitality settings, this unit seamlessly blends functionality and performance. It features three mic/line inputs, one aux input, and a built-in media player capable of handling connections through Bluetooth, USB/SD media, or an FM tuner, making it perfect for both music playback and public address requirements.

Technical Specifications & Product Details

• Power Output:240W (shared across 4 zones @ 100V)
• Inputs:3 x mic/line (jack/XLR), 1 x aux (RCA)
• Bluetooth Version:5.0 with programmable ID
• Weight:10.4kg
• Dimensions:430 x 315 x 89mm
• Power Supply:110/230Vac, 50/60Hz (IEC)
• Speaker Outputs:4 x 100V (modular terminal block)
• Output controls:Master volume, 4 x zone volumes & mutes
• Protection:Short circuit, overload, overheat
• Phantom Power:+20V (switchable on inputs 1-3)
• Call Station Input:2 x RJ45 for optional CS-4 call stations
• Fire Alarm Contacts:24V screw terminals for emergency evacuation
• Audio Source:USB/SD player, FM tuner and Bluetooth receiver
• Total Harmonic Distortion + Noise:< 2% @ 1kHz (rated power)
• Equaliser Controls:Bass ±10dB at 100Hz, Treble ±10dB at 10kHz
• Input Impedance:Mic: 5k Ohms, Line: 1k Ohms
• Input Sensitivity:Mic: -47dBV, Line: -10dBV
• Sends & Returns:Pre out, amp in (RCA)

Ideal Uses & Applications

This100V Mixer Amplifieris perfect for a wide array of environments. It excels in commercial applications, such as:

• Shops and retail environments seeking a reliable sound system for background music and announcements.
• Restaurants and cafes that require a seamless blend of music playback and paging capabilities.
• Event venues that need to manage sound effectively across different zones.
• Educational institutions needing a robust public address system.
• Hospitality settings that require announcements in multiple areas without the need for extensive additional equipment.

Energy Efficiency & Cost Savings

Operating with a 240W output across multiple zones, this mixer amplifier not only meets the demands of various settings but also promotes energy efficiency. By sharing power amongst four zones, users can ensure that they are not consumed with excess energy usage, leading to potential savings on electricity costs. Its advanced power supply supports 110/230Vac, operating efficiently under various conditions. Users could potentially see reductions in energy bills while ensuring optimal sound quality is maintained even at lower power outputs.

In conclusion, the100V Mixer Amplifier with 4-zone Pagingcombines quality, functionality, and efficiency for users requiring sound solutions in diverse environments. Its capability to integrate multiple audio sources while managing sound across different zones makes it a sturdy choice for any professional sound application.
