Comnet FVR10D1EM encoded video receiver, Rack Mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Comnet FVR10D1EM is an encoded video receiver from the FVT/FVR10D1E(M,S) range.
The Comnet FVT/FVR10D1E series video transmitter/receiver and data transceiver supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digital video with one bi-directional data channel plus one 10/100 Mbps fast Ethernet port. The modules are universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from most major manufacturers.
Packaged in the exclusive Comnet ComFit housing, the FVT/ FVR10D1E units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of Comnet model DINBKT1 adaptor plate.
Key features
- IEEE 802.3 Compliant
- Automatic resettable fuses on all power lines
- Status indicating LEDs provide rapid indication of critical operating parameters
- One bi-directional data channel
- One 10/100 BASE-T/TX fast Ethernet port
- Circuit boards are conformally coated to extend humidity tolerance to condensation conditions
- ComFit standard form factor is interchangeable between stand-alone or rack mount use
- Compatible with NTSC, PAL, or SECAM Video Standards
- Standard ComFit models are hot-swappable
- Electric Port Supports Auto-negotiation for Full Duplex or Half Duplex Data Throughput
If you are matching this to an existing installation, work from the FVR10D1EM part number rather than the description.
-
Download
- FVR10D1EM — Product Manual
Specifications
General information
Technical information
Certifications
Interfaces/ports
Product information
Specifications
| Brand Name | Comnet |
|---|---|
| Manufacturer Part Number | FVR10D1EM |
| Product Series | FVT/FVR10D1E(M,S) |
| Product Type | Video Extender Receiver |
General information
| Application/Usage | CCTV System, Networking System, Surveillance System |
|---|
Technical information
| Maximum Operating Distance | 3km |
|---|---|
| Media Type Supported | Fiber Optic |
Certifications
| RoHS compliance | Out of Scope |
|---|---|
| WEEE compliance | Compliant |
Interfaces/ports
| Network (RJ-45) | Yes |
|---|---|
| Number of Network (RJ-45) Ports | 1 |
| Number of ST Ports | 1 |
Product information
| Mount Type | Rack Mount |
|---|
