Comnet FVT1031M1 encoded video transmitter
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Comnet FVT1031M1 is an encoded video transmitter.
The Comnet FVT/FVR1031 transmits 10 bit digital video and full duplex data over one Singlemode or Multimode fiber. The video supports NTSC, PAL and SECAM CCTV camera systems. The data supports RS232, RS422 and RS485 (2W and 4W) at data rates up to 115 Kbps (NRZ).
The FVT/FVR1031 series also supports "UP-THE-COAX" control signals for Pelco and Panasonic cameras with a maximum distance of 590m. The product is "Plug-and-Play" with no electrical or optical adjustments.
Key features
- Supports RS232, RS422 or RS485 (2 or 4-wire) data interfaces
- Automatic resettable fuses on all power lines
- Status indicating LEDs provide rapid indication of critical operating parameters
- Distances up to 69 km
- Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events
- Compatible with NTSC, PAL, or SECAM Video Standards
- 10-Bit digitally encoded short-haul video transmission meets the requirements of the EIA RS-250C standard
- Standard ComFit models are hot-swappable
- ComFit standard form factor is designed for wall, surface, rack, or DIN rail mount installations (using optional card cage or DIN mounting bracket)
If you are matching this to an existing installation, work from the FVT1031M1 part number rather than the description.
-
Download
- FVT1031M1 — Product Manual
Specifications
Physical characteristics
Specifications
| Brand Name | Comnet |
|---|---|
| Manufacturer Part Number | FVT1031M1 |
| Product Type | Digital Multimedia Receiver |
Physical characteristics
| Depth | 154.90mm |
|---|---|
| Height | 27.90mm |
| Width | 134.60mm |
