Knight Fire & Security YF10CBA roller shutter contact
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Knight Fire & Security YF10CBA is a roller shutter contact from the YF10CBA range.
The Knight Fire YF10CBA is a waterproof roller shutter contact designed for security applications. It features universal handing with a left default setting, rotatable magnet for right-handed use, and includes a 1 metre armoured sleeving plus 1.2 metres of waterproof neoprene sleeving for inner cores. The unit provides heat shrink waterproofing at the cable entry to the PCB and supports magnetic interference detection along with selectable resistors.
Certified to Environmental Class IV, it measures 150mm x 40mm x 15mm, incorporates 8-wire terminals, and offers a tamper-sealed design with an operational gap of approximately 35mm.
Key features
- Universally handed (left by default – rotate magnet for right handed installations)
- 1 metre Armoured Sleeving
- 1.2 metres waterproof neoprene waterproof sleeving for inner cores
- Heat shrink waterproofing at cable entry to PCB
- Magnetic Interference Detection and Selectable Resistors
- Environmental Class IV
- Operation Gap: 35mm Approx
- Terminals: 8-Wire
- Dimensions- 150mm x 40mm x 15m
- Tamper: Sealed unit
If you are matching this to an existing installation, work from the YF10CBA part number rather than the description.
Specifications
Specifications
| Brand Name | Knight Fire & Security |
|---|---|
| Manufacturer Part Number | YF10CBA |
| Product Series | YF10CBA |
