Nitek EL1500U-WS1 media converter
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Nitek EL1500U-WS1 is a media converter.
The Nitek Etherstretch EL1500UWS Outdoor IP devices network extender-PoE Inserter with Surge Protector is another of the IP Video Transmission Solutions from Nitek. The System includes a Receiver, Transmitter, Surge Protector unit and a NEMA 4X rated enclosure to house the Transmitter and Surge unit. The system transmits IP devices over network category cables and can quickly turn any ordinary 4 pair category cable into a high speed network communication and PoE path.
When operating over UTP category cable, the network extender system can operate for distances of up to 600 meters (1968'). The EL1500UWS UTP Ethernet Extender System consists of a weatherproof enclosure which houses the Transmitter and Surge unit and a standard Receiver. The system requires very little installation time and absolutely no set up or configuration.
The EL1500U Ethernet Extender Transmitter and Receiver are transparent to the network and have no IP or MAC addressing. Simply connect your network devices to the network ports of the Transmitter and Receiver along with existing cabling and the system begins communicating. LED indicators show the status of network communication and PoE power.
When connected to a PoE switch, power from the switch is used as the power source for the connected EL1500UWS Receiver. In applications where network switches are not PoE capable, an optional power Inserter (IP1054 sold separately) can be used to insert power to the EL1500UWS Receiver. The power is sent from the Receiver over the UTP to the Transmitter.
The Transmitter uses PoE as its power source and powers the connected PoE network device as well. The EL1500UWS UTP Network Extender System extends network communications to overcome cable distance limitations offering connections to devices in locations traditional networking does not allow.
Key features
- Environmentally hardened - meets NEMA TS-1/TS-2
- Transmitter is fitted into a NEMA 4X rated enclosure to support outdoor applications
- Transmits up to distances of 600m (1968')
- Supports mega-pixel technology
- Supports any network device, including IP cameras
- Supports 10/100 and PoE over category rated cables
- Fully transparent to the network
- Easy to install, no set up required
- LED indicators for network signals, link status and power
- Optional power supply can insert PoE power for non-PoE switches
Specifications
Environmental conditions
Physical characteristics
Power description
Specifications
| Brand Name | Nitek |
|---|---|
| Manufacturer Part Number | EL1500U-WS1 |
Environmental conditions
| Operating Temperature (T-T) | -15-75°C |
|---|
Physical characteristics
| Depth | 129.54mm |
|---|---|
| Height | 27.94mm |
| Width | 40.64mm |
Power description
| Power over Ethernet (PoE) | Yes |
|---|
