Nitek EE328-W1 PoE extender
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Nitek EE328-W1 is a PoE extender.
The EE328W provides a weatherproof enclosure for the Network Repeater Unit EE328 that allows outdoor operation of repeating and extending Ethernet and PoE. The EE328 Ethernet and PoE Extender is designed to greatly extend the distance to which IP cameras and network devices can operate. The EE328 regenerates network communication and passes PoE power through itself and down the network cable.
Each EE328 unit extends the cable run by 100m or 328'. When used with an optional 48VCD power supply the EE328 can operate as a fully independent repeater and IEEE802.3af PoE inserter. If needed, several EE328 units can be used in series to extend a network communication and PoE by every 100m or 328'. (max.
5 extenders equals 600m or 1.968').
Key features
- Supports any network device, including IP cameras, Megapixel and 4K cameras
- Fully transparent to the network
- Easy to install, no set up required
- No MAC or IP addressing required
- Built-in Surge protection
- LED Indicators for Network signals, link status and power
- Optional power supply can insert PoE power for non-PoE switches
- Unit powered by PoE input or external power supply, passes PoE through
- Transmits data and PoE
- Can be daisy-chained for additional distance
If you are matching this to an existing installation, work from the EE328-W1 part number rather than the description.
Specifications
Environmental conditions
Physical characteristics
Power description
Specifications
| Brand Name | Nitek |
|---|---|
| Manufacturer Part Number | EE328-W1 |
Environmental conditions
| Operating Temperature (T-T) | -10-60°C |
|---|
Physical characteristics
| Depth | 40.13mm |
|---|---|
| Height | 222.00mm |
| Width | 145.80mm |
Power description
| Power over Ethernet (PoE) | Yes |
|---|
