MAG MAGPRO-HD1 Addressable Heat Detector
About this product
The MAG MAGPRO-HD1 is an Addressable Heat Detector. Featuring addressable operation, it is built for dependable professional installation.
Key Features
- Day/Night mode
- Low profile design
- LED indication with 360° visibility
- Base supplied separately MAGPRO-DB, MAGPRO-DBS
- Addressable operation
In Detail
Specified across commercial, industrial and multi-occupancy premises, ESP's fire detector products are engineered for reliable life-safety performance and straightforward installation by qualified engineers. Robust construction and clear indication help ensure the system performs when it matters.
A dependable fire alarm system relies on quality components working together, and this unit integrates cleanly with ESP panels, detectors and sounders — a well-supported platform to design around and maintain.
The MAG MAGPRO-HD1 is a practical choice wherever a reliable fire detector is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | MAG |
| Product code | MAGPRO-HD1 |
| Dimensions (mm) | ø103 x 42 |
| Colour | White |
| Materials | Housing: ABS |
| Available Classes (Selected from CIE) | A1R/A2S/BS |
| Weight (Kg) | 0.11 |
| Warranty (Years) | 3 |
| Operating Voltage (V DC) | 15 - 30 |
| Nominal Operating Voltage (V DC) | 27 |
| Protocol Type | Custom (Closed) |
| Operating Temperature (°C) | -10 to +60 |
| Relative Humidity Resistance (%) | 93 (±3) (@40˚C) |
| Compatible Products | Compatible with MAGPRO-DB, MAGPRO-DBS and MAGPRO-DBSS |
| GTIN | 5060224104866 |
| Commodity Code | 8531103000 |
