Ajax 106788.136.BL1 Wireless Combined Heat and CO Detector, 10-Year Battery Life
About this product
The Ajax FireProtect 2 SB (Heat/CO) Jeweller is a wireless combined heat and CO detector with sealed batteries, for Ajax security systems. It alarms on high temperature, rapid temperature rise and accumulated carbon monoxide, sounds an in-built siren at 85 dB at a distance of 3 meters, and reports to the hub over Jeweller at up to 1,700 m in an open space.
Key features
- Heat sensor to the requirements for Class A1R heat detectors (EN 54-5 and BS 5446-2)
- High temperature alarm above 64°C and temperature spike alarm when temperature rises more than 10°C in 1 minute or less
- Chemical CO sensor that alarms on accumulated CO dose
- In-built siren, volume 85 dB at a distance of 3 meters
- 2 non-replaceable lithium batteries with 10 years of battery life
- Jeweller radio range of up to 1,700 m in an open space
- Tampering alarm and SmartBracket mounting panel
Frequently asked questions
What does the Ajax FireProtect 2 SB (Heat/CO) detect?
Heat and carbon monoxide. It alarms at temperatures above 64°C, when the temperature rises more than 10°C in 1 minute or less, and when the accumulated dose of CO is exceeded.
Can the batteries in the FireProtect 2 SB be replaced?
No. It uses 2 non-replaceable lithium batteries with 10 years of battery life. The sensor life is also 10 years, after which the detector must be replaced with a new one.
How far from the hub can the detector be installed?
The radio communication range is up to 1,700 m between the detector and a hub (or radio signal range extender) in an open space.
Do other fire detectors sound when one detects a threat?
Yes. The hub initiates an interconnected alarm within 20 seconds. With fallback interconnection (firmware version 5.59.2 or later), the detector also alerts other detectors directly and all connected detectors activate the buzzer within a minute.
How loud is the built-in siren?
The in-built siren has a volume of 85 dB at a distance of 3 meters.
What is in the box?
The FireProtect 2 SB (Heat/CO) Jeweller detector, SmartBracket mounting panel, installation kit and quick start guide.
Specifications
Specifications
| Brand | Ajax |
|---|---|
| Model | 106788.136.BL1 |
| Manufacturer Part Number (MPN) | 106788.136.BL1 |
| Sensitive elements | heat sensor, CO (carbon monoxide) sensor |
| Heat sensitive element | Class A1R heat detectors |
| Heat detector standards | EN 54-5 and BS 5446-2 |
| High temperature alarm | at temperatures above 64°C |
| Temperature spike alarm | when the temperature rises more than 10°C in 1 minute or less |
| CO sensitive element | chemical CO sensor |
| Alarm if accumulated dose of CO is exceeded | more than 50 ppm (0.005%) — no more than in 90 minutes; more than 100 ppm (0.01%) — no more than in 40 minutes; more than 300 ppm (0.03%) — no more than in 3 minutes |
| Sensor life | 10 years |
| In-built siren | volume 85 dB at a distance of 3 meters |
| Communication | Jeweller communication technology |
| Radio communication range | up to 1,700 m (in an open space) |
| Maximum effective radiated power (ERP) | up to 20 mW |
| Radio signal modulation | GFSK |
| Detection of communication failure | within 15 minutes |
| Power supply | 2 non-replaceable lithium batteries |
| Battery life | 10 years |
| Dimensions | 44 × 86 × 86 mm |
| Weight | 145 g |
| Operating temperature range | from 0°C to +50°C |
| Operating humidity | up to 80% |
| Protection class | IP20 |
| Complete set | FireProtect 2 SB (Heat/CO) Jeweller, SmartBracket mounting panel, Installation kit, Quick start guide |
| Colour | Black |
