Hikvision DS-1LN6OUSPE Cat6 U/UTP Outdoor Network Cable, 305m, Black
Free Delivery
Save £31.52
About this product
The Hikvision DS-1LN6OUSPE is a Cat 6 U/UTP outdoor network cable with a solid-bare copper conductor and a black PE sheath, supplied as 305 ± 1.5 m. It is compliant with ANSI/TIA-568.2-D, IEC61156 and ISO/IEC11801, and gives excellent performance in the Fluke 100-meter channel test while continuously loaded with 57 V/1 A DC power (PoE).
Key features
- Cat 6 U/UTP construction
- Solid-bare copper conductor, 0.552±0.005 mm 23AWG
- PE sheath, usage scenario: outdoor
- Compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801 and RoHS 2.0
- Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature
- Excellent performance in the Fluke 100-meter channel test while continuously loaded with 57 V/1 A DC power (PoE)
- Sheath with high tensile and compressive strength
- 305 ± 1.5 m length
Frequently asked questions
Is the DS-1LN6OUSPE for indoor or outdoor use?
The usage scenario is outdoor.
Is the conductor solid copper?
Yes. The conductor material is solid-bare copper, with a conductor diameter of 0.552±0.005 mm 23AWG.
How long is the cable?
The length is 305 ± 1.5 m.
Has it been tested with PoE?
It gives excellent performance in the Fluke 100-meter channel test while continuously loaded with 57 V/1 A DC power (PoE).
Does it have a fire-resistance rating?
No. Its fire resistance is None.
Technical Details
Specifications
Brand
Hikvision
Model
DS-1LN6OUSPE
Manufacturer Part Number (MPN)
DS-1LN6OUSPE
Category
Cat 6
Structure
U/UTP
Fire Resistance
None
Usage Scenario
Outdoor
Sheath Material
PE
Sheath Color
Black
Conductor Material
Solid-Bare Copper
Conductor Diameter
0.552±0.005 mm 23AWG
Insulation Diameter
0.98 ±0.05mm
Length
305 ± 1.5 m
Rip Cord
Yes
Separator
Yes
Colour
Black
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-1LN6OUSPE |
| Manufacturer Part Number (MPN) | DS-1LN6OUSPE |
| Category | Cat 6 |
| Structure | U/UTP |
| Fire Resistance | None |
| Usage Scenario | Outdoor |
| Sheath Material | PE |
| Sheath Color | Black |
| Conductor Material | Solid-Bare Copper |
| Conductor Diameter | 0.552±0.005 mm 23AWG |
| Insulation Diameter | 0.98 ±0.05mm |
| Length | 305 ± 1.5 m |
| Rip Cord | Yes |
| Separator | Yes |
| Colour | Black |
