Hikvision DS-D4215MI-070H(B) LED Poster Display, P1.5, 600 cd/m²
About this product
The Hikvision DS-D4215MI-070H(B) is a P1.5 LED poster display in a vertical design, with a 1.5625 mm pixel pitch, 384 × 1080 resolution and 600 cd/m² brightness. It can be used singly or horizontally spliced with further units, and supports tilt bracket, wall, pendant and mobile base mounting.
Key features
- P1.5 pixel pitch category, with a 1.5625 mm pixel pitch
- 384 × 1080 resolution from SMD Triad LED pixels
- 600 cd/m² brightness and a contrast ratio of ≥ 3000:1
- Refresh rate up to 3840 Hz and grey level up to 16 bit
- Viewing angle horizontal 160°, vertical 160°
- Magnetic butterfly bezel design that supports splicing of multiple screens
- Content managed via local storage, USB flash drive, mobile client or PC client
- Front maintenance for cabinet, and rear maintenance for system backpack
Frequently asked questions
What is the pixel pitch of the DS-D4215MI-070H(B)?
The pixel pitch is 1.5625 mm, in the P1.5 pixel pitch category.
What resolution and brightness does it have?
Resolution is 384 × 1080 and brightness is 600 cd/m².
What power does it need?
The power supply is 110 to 220 VAC ± 15%, with max. consumption of ≤ 450 W/m² and average consumption of < 150 W/m².
What comes in the box?
The packing list is power cord × 1, HDMI × 1 and Wi-Fi antenna × 2.
How can the display be mounted?
It supports tilt bracket mounting, mobile two-color alloy base mounting, wall mounting, pendant mounting and creative bracket mounting.
How much does it weigh?
The display weighs 29 kg (64.0 lb.), and the gross weight is 35 kg (77.2 lb.).
Specifications
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-D4215MI-070H(B) |
| Manufacturer Part Number (MPN) | DS-D4215MI-070H(B) |
| Pixel Configuration | SMD Triad LED |
| Pixel Pitch Category | P1.5 |
| Pixel Pitch | 1.5625 mm |
| Resolution | 384 × 1080 |
| Pixel Density | 409600 dots/m² |
| Area | 1.0125 m² |
| Dimensions (W × H × D) | 613 × 1695.5 × 68.1 mm (24.1 × 66.8 × 2.7 inch) |
| Weight | 29 kg (64.0 lb.) |
| Gross Weight | 35 kg (77.2 lb.) |
| Lamp Board Housing | Without housing, glue potting |
| Cabinet Material | Aluminum alloy |
| Maintenance Method | Front maintenance for cabinet, and rear maintenance for system backpack |
| Brightness | 600 cd/m² |
| Colour Temperature | 3000 to 10000 K adjustable |
| Viewing Angle | Horizontal 160°, vertical 160° |
| Contrast Ratio | ≥ 3000:1 |
| Brightness Uniformity | ≥ 97% |
| Driving Method | Constant current driving |
| Frame Frequency | 60 Hz |
| Refresh Rate | Up to 3840 Hz |
| Grey Level | Up to 16 bit |
| Power Supply | 110 to 220 VAC ± 15% |
| Max. Consumption | ≤ 450 W/m² |
| Average Consumption | < 150 W/m² |
| Working Temperature | -10 to 40 ° C (14 to 104 ° F) |
| Working Humidity | 10% to 60% RH (non-condensing) |
| Storage Temperature | -20 to 60 ° C (-4 to 140 ° F) |
| Packing List | Power cord × 1, HDMI × 1, Wi-Fi antenna × 2 |
