Redvision RV-POE-INJ-90W 90W PoE Injector, IEEE 802.3af/at/bt, 10/100/1000Mbps
About this product
The Redvision RV-POE-INJ-90W is a 90W PoE injector for the Redvision X-series PTZ cameras, compatible with X2 COMBAT, X3 STORM and X4 COMMANDER PoE models. It supports IEEE 802.3af/at/bt at 10/100/1000Mbps and is plug and play, without configuration management.
Key features
- 90W PoE injector for X-series PTZ cameras
- PoE++/IEEE802.3bt, IEEE802.3af/at downward compatible
- 10/100/1000Mbps data on 1×RJ45 data input and 1×RJ45 PoE output
- Output 55Vdc, 1.65A from an AC100-240V; 50/60Hz, 1.4A Max. input
- Plug and play, without configuration management
- Metal enclosure with natural heat dissipation
- Under-voltage, over-voltage, over-current and short-circuit protection, Lighting Protection 3KV 8/20us and 3KV ESD protection
Frequently asked questions
Which Redvision cameras is the RV-POE-INJ-90W for?
It is the 90W power over ethernet injector for the X-series PTZ cameras, compatible with X2 COMBAT, X3 STORM and X4 COMMANDER PoE models.
Which PoE standards does it support?
PoE++/IEEE802.3bt, with IEEE802.3af/at downward compatible.
What mains input does it need?
AC100-240V; 50/60Hz, 1.4A Max., through an AC Power Socket (ICE320-C14 Standard).
Does it need configuring?
No. It is plug and play, without configuration management.
How long can the cable run be at gigabit speed?
For 1000Base-T, Pair 4 Category 5(Cat5e) and above UTP/STP(≤90m), or Pair 4 Category 6(Cat6e) and above UTP/STP(≤100m).
What protection does it have?
Under-voltage, over-voltage, over-current and short-circuit protection, Lighting Protection 3KV 8/20us; 3KV ESD protection.
Specifications
Specifications
| Brand | Redvision |
|---|---|
| Model | RV-POE-INJ-90W |
| Manufacturer Part Number (MPN) | RV-POE-INJ-90W |
| Item | 90W PoE Injector |
| Input Voltage/Frequency | AC100-240V; 50/60Hz, 1.4A Max. |
| Output Voltage/Current | 55Vdc, 1.65A |
| Power Input | AC Power Socket (ICE320-C14 Standard) |
| Ethernet Port (Data Input) | 1×RJ45 10/100/1000Mbps |
| Ethernet Port (PoE Output) | 1×RJ45 10/100/1000Mbps |
| Power/Data Assignment | Power: pin 1,2,4,5“+”, pin 3,6,7,8 ”-”; Data: pin 1,2,3,4,5,6,7,8 |
| Data Exchange | 10/100/1000Mbps |
| Network Medium (1000Base-T) | Pair 4 Category 5(Cat5e) and above UTP/STP(≤90m); Pair 4 Category 6(Cat6e) and above UTP/STP(≤100m) |
| Protections | Under-voltage, over-voltage, over-current and short-circuit protection, Lighting Protection 3KV 8/20us; 3KV ESD protection |
| Ambient operating temperature | -10~65℃ |
| Storage temperature | -40~70℃ |
| Operating Humidity | 10%~90% RH, no condensation |
| System Reliability | MTBF＞100k hours |
| Specification | PoE++/IEEE802.3bt, IEEE802.3af/at downward compatible |
| Comply to | EN55022, CLASS B CE＆RE, CE, FCC, RoHS |
| Dimension/Weight | 183mm×72mm×35mm; N.W : 0.40Kg, G.W : 0.60Kg |
