TOA CS-64 Wide-Range Weatherproof Horn Speaker, 6 W, 96 dB
About this product
The TOA CS-64 is a wide-range weatherproof horn speaker for paging, background music and tone signalling distribution on 100 V and 70 V lines. It is rated at 6 W, with a sensitivity of 96 dB (1 W, 1 m) and stainless steel hardware for all-weather durability.
Key features
- Rated input 6 W
- Sensitivity 96 dB (1 W, 1 m)
- Frequency response 130 - 13,000 Hz
- Transformer taps: 1 W, 3 W, 6 W at 100 V; 0.5 W, 1.5 W, 3 W, 6 W at 70 V
- Rotary switch for impedance changes
- Exponential horn for uniform and clear sound dispersion
- Stainless steel hardware protects the speaker from corrosion
- Wide temperature range: -20 to +55 °C
Frequently asked questions
Can the TOA CS-64 be used outdoors?
Yes. The CS-64 is an outdoor speaker with stainless steel hardware for all-weather durability.
What power taps does the CS-64 have?
1 W, 3 W and 6 W at 100 V, and 0.5 W, 1.5 W, 3 W and 6 W at 70 V, changed with a rotary switch.
What are the sensitivity and frequency response of the CS-64?
Sensitivity is 96 dB (1 W, 1 m) and frequency response is 130 - 13,000 Hz.
Are there any mounting restrictions for the CS-64?
Do not install the speaker face-up from a horizontal plane, nor in such a way that the paper cone is exposed to direct sunlight.
What temperature range does the CS-64 cover?
It has a wide temperature range of -20 to +55 °C.
Specifications
Specifications
| Brand | TOA |
|---|---|
| Model | CS-64 |
| Manufacturer Part Number (MPN) | CS-64 |
| Rated input | 6 W |
| Rated impedance (100 V line) | 1.7 kΩ (6 W), 3.3 kΩ (3 W), 10 kΩ (1 W) |
| Rated impedance (70 V line) | 830 Ω (6 W), 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W) |
| Sensitivity | 96 dB (1 W, 1 m) |
| Frequency response | 130 - 13,000 Hz |
| Dispersion | 100° (H) x 100° (V) at –6 dB below the on-axis reference at 2 kHz |
| Speaker component | 12 cm cone-type (treated for splash proof) |
| Speaker cable | 2-core cabtyre cord with diameter of 6 mm |
| Temperature range | -20 to +55 °C |
| Finish (horn, cover) | ABS resin, off-white, paint |
| Finish (bracket) | Stainless steel |
| Finish (net) | Surface treated steel plate, dark-gray, powder coating |
| Finish (screw) | Stainless steel |
| Dimensions | 233 (W) x 224 (H) x 208 (D) mm |
| Weight | 1.5 kg |
| Colour | Off-white |
