Nitek EL1551U network extender
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Nitek EL1551U is a network extender.
The EL1551U is a transmitter-receiver system which extends 100Mbps of Ethernet communication over a single pair of communication wires up to 460 meters (1500 feet) . The EL1551U is a component of the NITEK cutting edge EtherStretch Pro™ product line that turns any ordinary pair of wires, such as UTP or any 2 conductor cable into a high speed network communication path. The system is transparent to the network and requires very little installation time, with no setup or configuration needed.
Simply connect your network devices to the network ports of the transmitter and receiver along with existing cabling and the system begins communicating. The EL1551U system is ideal for upgrading analog UTP video balun systems to IP systems without needing to replace or even disturb the existing cable infrastructure. Power is provided to the ET1551U transmitter from the ER1551U receiver unit.
LED indicators show the status and speed of network communications.
Key features
- Environmentally hardened - meets NEMA TS-1/TS-2
- Transmits up to distances of 460 meters (1500')
- Supports mega-pixel technology
- Fully transparent to the network
- Upgrades systems from analog to IP cameras
- Supports 10/100 over Twisted Pair cables
- Easy to install, no set up required
- No MAC or IP addressing required
- LED indicators for network signals, link status and power
- Optional power supply can insert PoE power for non-PoE switches
If you are matching this to an existing installation, work from the EL1551U part number rather than the description.
-
Download
- EL1551U — Product Manual
Specifications
Technical information
Certifications
Interfaces/ports
Miscellaneous
Attributes
Specifications
| Brand Name | Nitek |
|---|---|
| Manufacturer Part Number | EL1551U |
| Product Type | Network Extender |
Technical information
| Maximum Data Transfer Rate | 12.5Mbps |
|---|
Certifications
| RoHS compliance | Compliant |
|---|---|
| WEEE compliance | Compliant |
Interfaces/ports
| Network (RJ-45) | Yes |
|---|
Miscellaneous
| Environmental certification | RoHS |
|---|
Attributes
| Environmental status | Yes |
|---|
Nitek EL1551U network extender
