Sangamo Q550.13.12 Astro Zone 2, 3 Pin Time Switch, 1 On/Off, Day Omit Skips ON Operation
About this product
The Sangamo Q550.13.12 is an Astro Zone 2, 3 Pin Time Switch, 1 On/Off, Day Omit Skips ON Operation. Featuring astro programming, it is built for dependable professional installation.
Key Features
- Astro zone 2
- Day omit skips on operation
- Temporary override (manual button)
- Astro programming
- Genuine ESP time switch supplied by WME
In Detail
An astro time switch tracks sunrise and sunset for its geographic zone, giving true dusk-to-dawn control of security, outdoor and amenity lighting without a separate photocell. Set the zone and it adjusts automatically through the year.
Ideal as an outdoor light timer for signage, car parks, forecourts and communal areas, it keeps lighting on only when needed — cutting energy use, with robust construction and simple programming.
The Sangamo Q550.13.12 is a practical choice wherever a reliable outdoor light timer is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | Sangamo |
| Product code | Q550.13.12 |
| Number of Outputs | 1 |
| Display | 24 Hour Dial |
| Relay/Contact Type | SPST |
| Timing Accuracy | 5 Minutes / Year |
| Relay Voltage - Maximum (AC) | 230 |
| Time Base | Quartz Crystal |
| Relay Resistive Load Rating (A) | 20 |
| Mounting | Surface Mounting |
| Base Type | 3 Pin |
| Maximum Inductive Current Rating (A) | 5 |
| Available Operations | 1 ON/OFF Period |
| Maximum Incandescent, Halogen Lamp | 3600 |
| Dial Calibration | Zone 2 |
| Maximum Fluorescent Lamp Load Rating | 1980 |
| Sunrise/Sunset Time Offset (Mins) | (+/-) 45 |
| Supply Voltage (V AC) | 230 |
| Power Consumption (W) | 0.6 |
| Cable Size (mm²) | 0.5 - 4 |
| Power Reserve | 20 Days |
| IEC Protection Class | Class I (Must be Earthed) |
| Operating Temperature (°C) | 0 to +50 |
| Dimensions | 104 × 83 × 134 mm |
| Weight | 0.465 kg |
| GTIN | 5026961000595 |
| Commodity Code | 9107000090 |
