Videx 4832-1/C/M camera/speaker module, Aluminium, Stainless Steel
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx 4832-1/C/M is a camera/speaker module.
4000 series combined speaker / camera modules are available for analogue system. The speaker / camera modules themselves are available with either 0, 1 or 2 buttons buttons, and a further 62 buttons may be added using 4842, 4843, 4844 and 4845 4000 series button modules. These 4000 Series modules are equipped with a colour day/night CCD camera with auto iris lens, complete with 6 infra-red LEDs for illumination.
The camera has vertical and horizontal adjustment (10 degrees). The unit can be configured to work on systems with coax video signals or on systems using balanced video signals (non-coax) by setting video mode with the use of jumpers. Modules contain a heating element to prevent the lexan window misting.
All modules contain a speaker and fly lead with microphone which is easily fitted to a 4000 series frame. Modules attached to the housing frames using a simple but strong clip in system. Speech levels may be adjusted using separate adjustment for both the speaker and microphone.
Key features
- Contains speaker and fly lead microphone (microphone easily fits within a 4000 Series frame)
- Speech volume adjustment (both directions)
- Up to 64 functional call buttons in total
- Blue illuminated name window
- Matt 316 stainless steel front plate
- Simple but strong clip in system
- Colour CCD day / night camera
- Infra-red LED illumination
- Vertical and horizontal adjustment (10 degrees)
If you are matching this to an existing installation, work from the 4832-1/C/M part number rather than the description.
Specifications
Physical characteristics
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | 4832-1/C/M |
Physical characteristics
| Durability | Durable |
|---|---|
| Material | Aluminium, Stainless Steel |
