Videx 4534X-0/BL colour video module

Free Delivery
£ 832 00
(Incl. VAT)

About this product

Please note: this is a non-returnable item (excluding faulty goods)

Videx 4534X-0/BL is a colour video module.

4000 series speaker/camera module, 4534X, is a combined speech amplifier and camera for the Videx IP system. The module is available with either 0, 1 or 2 buttons (however when connected to 4000 series button expansion modules via the IDC connector can have up to 42 buttons on the system) and have blue backlit name plate windows. It also includes a built-in proximity reader located behind button 1 name plate window.

The total fob/card user capacity for this module is up to 10,000 user fobs/cards (programmable via the IP Wizard). The modules are equipped with a CMOS wide angle colour camera with a vertical viewing angle of 80° and a horizontal viewing angle of 170°, complete with 4 bright white illumination LEDs. It supports H.264 video codec and supports 1280—720, 640—480, 352—288 (CIF) and 320—240 resolutions and has SIP 2.0 compatibility.

The modules also have 4 DDA compliant call progress LEDs to advise the user when the system is busy, a call is in progress, when to speak and when the door is open and includes voice annunciation and acoustic signals. Other programmable settings such as speech volume levels, door relay time, conversation time can be adjusted and setup via the IP Wizard. The modules can be powered directly with 12Vdc or via PoE.

All modules contain a speaker and fly lead with microphone which easily fits into a 4000 series frame. Modules attach to the housing frames using a simple but strong clip in system. All the modules are available in a matt 316 marine grade stainless steel finish (suffix /M) or gun metal grey (suffix /BL).

Substitute /M with /BL for gun metal grey finish e.g. 4534X-1/BL.

Key features

  • Compatible with the full range of 4000 Series surface and flush back boxes
  • Matt 316 marine grade stainless steel (/M) or gun metal grey (/BL) front plate finishes available
  • Blue backlit name plate windows
  • Wide angle CMOS colour camera with white light LED illumination
  • DDA compliant call progress LED's, voice annunciation and acoustic signals
  • Contains speaker and fly lead microphone (microphone easily fits within a 4000 Series frame)
  • Built-in proximity access reader for up to 10,000 user fobs/cards (programmable via PC based IP Wizard)
  • H.254 video codec
  • Supported resolutions 1280x720, 640x480, 352x288 (CIF) and 320x240
  • SIP 2.0 compatible

If you are matching this to an existing installation, work from the 4534X-0/BL part number rather than the description.

£ 832 00
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£832.00 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand Name
Videx
Manufacturer Part Number
4534X-0/BL
Specifications

Specifications

Brand Name Videx
Manufacturer Part Number 4534X-0/BL

Videx 4534X-0/BL colour video module

Videx 4534X-0/BL colour video module

Who this is for

For the installer — this is the colour video module supplied under Videx part number 4534X-0/BL. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is a colour video module made by Videx. The part number 4534X-0/BL is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this colour video module is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is non-returnable, excluding faulty goods. That restriction comes from the manufacturer's own terms for this line.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact colour video module I have been quoted? Check the manufacturer part number 4534X-0/BL against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Not on this listing.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against 4534X-0/BL answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.
