Videx 4202/1/S digital audio panel
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx 4202/1/S is a digital audio panel from the 4000 range.
The 4000 series digital video panel range compliments the VX2200 digital system. The digital module is built into 4000 series double modules and have either an alpha-numeric keypad (4202V/1/C) with standard key buttons 1-9, enter, 0, clear and A-F) or a numeric keypad with name scroll facility (4202V/1R/C with standard key buttons 1-9, enter, 0 clear and prev, call, next buttons).All panels incorporate features from other VX2200 digital panels; storing up to 255 users (up to 998 with the inclusion of a block exchangers 2206N), allowing each user to have a unique 4-6 digit access code, trade facility, multiple language display and speech board annunciation.The digital modules also includes a blue back-lit 2-line 16-character LCD display and speaker unit. They also incorporate microphone, speaker and speech balance control adjustments.
The digital modules are available in either a flush 2-module backbox (4852) or a surface 2-module backbox (4882) and come in a stainless steel finish. In addition the digital panel includes a color CCD camera with IR illumination LED's that provide the best quality picture in any lighting condition with a 10° camera orientation adjustment. The camera can be set to work with either composite video (coax) or balanced video (non-coax twisted pair) and is protected behind a strengthened polycarbonate window.
Programming is carried out using the built-in numeric keypad or by using the VX2200 PC software kit (SP37) which includes the programming software and a serial RS232 connection cable.
Key features
- Alpha-numeric keypad or name scroll facility
- Flush (4852) or surface (4882) mounting options
- Blue back-lit 2x16 character LCD display providing visual messages
- Speech annunciation call progress
- Programmable door access codes (up to 1000 access codes)
- Program up to 255 apartments (up to 998 with 2206N block exchangers)
- BUS Cabling system (minimum 6 wires)
- Serial RS232 jack plug connection for PC programming
- Dry contact relay lock output
- Timed call, speech and lock release
If you are matching this to an existing installation, work from the 4202/1/S part number rather than the description.
Specifications
Physical characteristics
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | 4202/1/S |
| Product Series | 4000 |
| Product Type | Door Panel |
Physical characteristics
| Depth | 15.70mm |
|---|---|
| Height | 240.00mm |
| Width | 103.00mm |
