Ajax 63208.168.WH1 FireProtect 2 RB Wireless Heat Detector, Replaceable Batteries, 85 dB Siren (at 3 m)
About this product
The Ajax FireProtect 2 RB (Heat) Jeweller (63208.168.WH1) is a wireless heat detector with replaceable batteries that raises an alarm at temperatures above 64°C or when the temperature rises more than 10°C in 1 minute or less. Its in-built siren sounds at 85 dB at a distance of 3 meters, and it communicates with a hub over Jeweller radio at up to 1,700 m in an open space.
Key features
- High temperature alarm at temperatures above 64°C
- Temperature spike alarm when the temperature rises more than 10°C in 1 minute or less
- Sensitive element built to the requirements for Class A1R heat detectors (EN 54-5 and BS 5446-2)
- In-built siren: volume 85 dB at a distance of 3 meters
- Jeweller radio communication range up to 1,700 m in an open space
- 2 × CR123A replaceable batteries with up to 7 years of battery life
- Front-panel button runs the detector test and silences the sound notification during an alarm or malfunction
- Tampering alarm on attempts to detach the detector from the surface or remove the mounting panel
Frequently asked questions
At what temperature does the FireProtect 2 RB (Heat) raise an alarm?
It raises a high temperature alarm at temperatures above 64°C, and a temperature spike alarm when the temperature rises more than 10°C in 1 minute or less.
What batteries does it use and how long do they last?
It uses 2 × CR123A batteries, pre-installed, with up to 7 years of battery life. The RB version has replaceable batteries.
How loud is the built-in siren?
The in-built siren has a volume of 85 dB at a distance of 3 meters.
Do the detectors sound together?
Yes. If one fire detector detects a threat, it sends an alarm to the hub, and within 20 seconds the hub initiates an interconnected alarm and sends data to Ajax apps.
Can it be installed outdoors?
No. The device is designed only for indoor installation, and its protection class is IP20.
What is in the box?
FireProtect 2 RB (Heat) Jeweller, SmartBracket mounting panel, installation kit, 2 × CR123A battery (pre-installed) and a Quick Start Guide.
Specifications
Specifications
| Brand | Ajax |
|---|---|
| Model | 63208.168.WH1 |
| Manufacturer Part Number (MPN) | 63208.168.WH1 |
| Communication | Jeweller communication technology |
| Maximum effective radiated power (ERP) | up to 20 mW |
| Radio signal modulation | GFSK |
| Radio communication range | up to 1,700 m (between the detector and a hub or radio signal range extender, in an open space) |
| Sensitive element | Class A1R heat detector requirements (EN 54-5 and BS 5446-2 standards) |
| High temperature alarm | at temperatures above 64°C |
| Temperature spike alarm | when the temperature rises more than 10°C in 1 minute or less |
| In-built siren | volume 85 dB at a distance of 3 meters |
| Protection against spoofing | device authentication |
| Power supply | 2 × CR123A battery |
| Battery life | Up to 7 years |
| Dimensions | 44 × 86 × 86 mm |
| Weight | 146 g |
| Operating temperature range | from 0°С to +50°С |
| Operating humidity | up to 80% |
| Protection class | IP20 |
| Colour | White |
Ajax 63208.168.WH1 FireProtect 2 RB Wireless Heat Detector, Replaceable Batteries, 85 dB Siren (at 3 m)
