Ajax 106792.136.BL1 FireProtect 2 SB (CO) Wireless CO Detector, Jeweller, Sealed Batteries
About this product
The Ajax FireProtect 2 SB (CO) Jeweller 106792.136.BL1 is a wireless CO detector with sealed batteries for Ajax security systems, designed only for indoor installation. It raises an alarm when the accumulated dose of CO is exceeded, sounds an in-built siren with a volume of 85 dB at a distance of 3 meters, and reports to the hub over Jeweller radio at up to 1,700 m in an open space.
Key features
- Chemical CO sensor with a sensor life of 10 years
- 2 non-replaceable lithium batteries with 10 years of battery life
- In-built siren: volume 85 dB at a distance of 3 meters
- Radio communication range up to 1,700 m between the detector and a hub in an open space
- Interconnected fire detectors alarms: within 20 seconds, the hub initiates an interconnected alarm
- Tampering alarm alerts of attempts to detach the detector or remove the mounting panel
- SmartBracket mounting panel allows adjusting the position of the detector after installation
Frequently asked questions
What batteries does the FireProtect 2 SB (CO) use?
It has 2 non-replaceable lithium batteries with 10 years of battery life.
At what CO levels does it raise an alarm?
It alarms if the accumulated dose of CO is exceeded: more than 50 ppm (0.005%) — no more than in 90 minutes; more than 100 ppm (0.01%) — no more than in 40 minutes; more than 300 ppm (0.03%) — no more than in 3 minutes.
How long does the CO sensor last?
The sensor life is 10 years. After 10 years of operation, the detector must be replaced with a new one.
What is the wireless range to the hub?
Up to 1,700 m between the detector and a hub (or radio signal range extender) in an open space.
Do the detectors alarm together?
Yes. If one of the fire detectors in the system detects a threat, it sends an alarm to the hub, and within 20 seconds the hub initiates an interconnected alarm and sends data to Ajax apps.
Can it be installed outdoors?
No. The device is designed only for indoor installation, with protection class IP20 and an operating temperature range from 0°C to +50°C.
Specifications
Specifications
| Brand | Ajax |
|---|---|
| Model | 106792.136.BL1 |
| Manufacturer Part Number (MPN) | 106792.136.BL1 |
| Communication | Jeweller communication technology |
| Maximum effective radiated power (ERP) | up to 20 mW |
| Radio signal modulation | GFSK |
| Radio communication range | up to 1,700 m (between the detector and a hub or radio signal range extender, in an open space) |
| Sensitive element | chemical CO sensor |
| Alarm if accumulated dose of CO is exceeded | more than 50 ppm (0.005%) — no more than in 90 minutes; more than 100 ppm (0.01%) — no more than in 40 minutes; more than 300 ppm (0.03%) — no more than in 3 minutes |
| Sensor life | 10 years |
| In-built siren | volume 85 dB at a distance of 3 meters |
| Detection of communication failure | within 15 minutes (depends on the settings for the number of undelivered data packages; polling interval fixed at 300 seconds) |
| Power supply | 2 non-replaceable lithium batteries, 10 years of battery life |
| Dimensions | 44 × 86 × 86 mm |
| Weight | 143 g |
| Operating temperature range | from 0°C to +50°C |
| Operating humidity | up to 80% |
| Protection class | IP20 |
| Colour | Black |
