Ajax 35291.40.BL1 Hub 2 Plus Wireless Control Panel, Up to 200 Devices, Photo Verification
About this product
The Ajax Hub 2 Plus Jeweller (35291.40.BL1) is a wireless control panel with support for photo verification, connectable via Wi-Fi, Ethernet, and two SIM cards (2G/3G/LTE). It manages up to 200 wireless Ajax devices and up to 200 users, and is designed for indoor installation only.
Key features
- Up to 200 wireless Ajax devices, including up to 10 sirens or keypads with a built-in siren and up to 5 range extenders
- Jeweller radio signal range up to 2,000 m in an open space (maximum range depends on the connected device)
- Wings photo verification channel, radio signal range up to 1,700 m in an open space
- Ethernet (1 8P8C socket, up to 100 Mbps), Wi-Fi 802.11 b/g/n and 2 micro-SIM slots
- Photo by alarm, by scenario, on demand and by schedule
- Built-in Li-ion 3 А·h backup battery: up to 15 hours of offline operation when Ethernet is disconnected
- Up to 64 automation scenarios, up to 25 security groups and up to 50 rooms
- Monitoring protocols: SIA (DC-09), SurGard (Contact ID), ADEMCO 685
Frequently asked questions
How many devices can the Hub 2 Plus Jeweller support?
Up to 200 wireless Ajax devices, including up to 10 sirens or keypads with a built-in siren and up to 5 range extenders. It also supports up to 200 users.
How does the hub connect to the internet?
It is connectable via Ethernet (1 8P8C socket, up to 100 Mbps), Wi-Fi (802.11 b/g/n) and two SIM cards (2G/3G/LTE) in 2 micro-SIM slots. The channels work in parallel and most of the data is transmitted via Ethernet.
Does the hub have a backup battery?
Yes. A built-in Li-ion 3 А·h backup rechargeable battery gives up to 15 hours of offline operation when Ethernet is disconnected.
Does it support photo verification?
Yes. It supports photo by alarm, photo by scenario, photo on demand and photo by schedule, and photos arrive in up to 9 s by default. Photo by Schedule needs hub firmware version OS Malevich 2.19 or higher.
Can it report to a monitoring station?
Yes. Supported monitoring protocols are SIA (DC-09), SurGard (Contact ID), ADEMCO 685 and other proprietary protocols.
What is in the box?
Hub 2 Plus Jeweller, SmartBracket mounting panel, power cable, Ethernet cable, installation kit, SIM card (depends on the sales region) and quick start guide.
Specifications
Specifications
| Brand | Ajax |
|---|---|
| Model | 35291.40.BL1 |
| Manufacturer Part Number (MPN) | 35291.40.BL1 |
| Wireless Ajax devices | up to 200 (up to 10 sirens or keypads with a built-in siren and up to 5 range extenders) |
| Users | up to 200 |
| Automation scenarios | up to 64 |
| Security groups | up to 25 |
| Rooms | up to 50 |
| Jeweller radio signal range | up to 2,000 m (in an open space) |
| Wings radio signal range | up to 1,700 m (in an open space) |
| Polling interval | from 12 to 300 s |
| Ethernet | 1 8P8C socket, up to 100 Mbps |
| Cellular | 2 micro-SIM slots |
| Wi-Fi | 802.11 b/g/n module, up to 600 Mbps |
| Supported notification types | Push-notifications, SMS, Calls |
| Photo transmission time | up to 9 s (by default) |
| Photo resolution | up to 640 × 480 pixels (depends on the detector) |
| Number of photos in a series | from 1 to 5 pictures |
| Monitoring protocols | SIA (DC-09), SurGard (Contact ID), ADEMCO 685, other proprietary protocols |
| Main power supply | 110–240 V~, 50/60 Hz |
| Mains power consumption | Up to 10 W |
| Backup battery | Li-ion 3 А·h (up to 15 hours of offline operation when Ethernet is disconnected) |
| Alternative power | 6 V⎓ or 12–24 V⎓ (PSU type A sold separately) |
| Plug type | Type G |
| Dimensions | 163 × 163 × 36 mm |
| Weight | 367 g |
| Operating temperature range | from −10°C to +40°C |
| Operating humidity | up to 75% |
| Protection class | IP20 |
| Colour | Black |
