Ajax Systems 140349.122.BL1 NVR, 8
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The Ajax 140349.122.BL1 is the NVR HDC (8-ch) in black: an 8-channel network video recorder with HDMI output, powered by a low-voltage power supply. It supports Ajax cameras and ONVIF-conformant IP cameras, and holds one SATA drive of up to 16 TB (drive not included).
Key features
- 8 video input channels; recording resolutions include 8MP, 4MP and 1080p
- H.265, H.264 and JetSparrow decoding; HDMI output at 1920 × 1080, 1600 × 1200, 1280 × 1024 or 1280 × 720 px
- Motion detection on 8 channels, by NVR HDC or by the camera's algorithms (switchable in an Ajax app); AI object detection on 8 channels with Ajax cameras
- 1 × SATA for a 2.5″ or 3.5” HDD or SSD of up to 16 TB; HDD or SSD not included
- Works with Ajax cameras, IP cameras that conform to ONVIF Profiles, and RTSP; conformant with ONVIF Profile G and S
- Built-in video management: video wall with live camera views, smart event filters and an interactive timeline
- Events triggered by Ajax detectors can automatically highlight the corresponding camera on the video wall
- 8–16 V DC, up to 4 A (without the PSU-board jumper); up to 24 W; indoor installation only (IP20)
Frequently asked questions
How many cameras can it record?
It has 8 video input channels, with motion detection on 8 channels.
Does it come with a hard drive?
No: HDD or SSD is not included. It has 1 × SATA, supporting a 2.5″ or 3.5” drive of up to 16 TB.
Does it work with non-Ajax cameras?
It supports IP cameras that conform to ONVIF Profiles and RTSP, as well as Ajax cameras, and is conformant with ONVIF Profile G and S.
What power supply does it need?
8–16 V DC, up to 4 A, without a jumper on the PSU board, or 12.4–16 V DC, up to 4 A, with the jumper installed. Power consumption is up to 24 W.
Can it be installed outdoors?
No: the device is designed for indoor installation only, and its protection class is IP20.
What is in the box?
The NVR HDC (8-ch), a SmartBracket mounting panel, a terminal adapter, an Ethernet cable, an installation kit and a quick start guide.
Specifications
Technical information
Physical characteristics
Specifications
| Brand Name | Ajax Systems |
|---|---|
| Manufacturer Part Number | 140349.122.BL1 |
| Product Type | NVR |
| Model | NVR HDC (8-ch) |
| Video Inputs | 8 channels |
| Recording Resolution | 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| HDMI Output Resolution | 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720 px |
| Decoding Format | H.265, H.264, JetSparrow |
| Decoding Capability | 1 × channel at 8MP; 3 × channel at 5MP; 4 × channel at 4MP; 4 × channel at 1080p; 8 × channel at 720p; 8 × channel at 1024 × 576 px |
| Synchronous Playback | 8 channels |
| Storage | 1 × SATA, drive up to 16 TB (2.5″ or 3.5” form factor); HDD or SSD not included |
| Network Interface | 1 × RJ-45 self-adaptive Ethernet (10/100 Mbps) |
| USB | Rear panel: 1 × USB 2.0 (Type-A); side panel: 1 × USB 2.0 (Type-A) |
| Bandwidth | Incoming up to 80 Mbps; outgoing up to 40 Mbps |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP, DNS |
| ONVIF | Conformant with ONVIF Profile G and S |
| Power Supply | 8–16 V DC, up to 4 A (without PSU-board jumper); 12.4–16 V DC, up to 4 A (with jumper) |
| Power Consumption | Up to 24 W |
| Clock Battery | CR2032, 3 V (system clock only) |
| Protection Class | IP20 |
| Operating Humidity | Up to 75% |
| Dimensions | 8.33″ × 8.33″ × 2.50″ |
| Weight | 1.66 lb (without a drive) |
| Operating Temperature | 32 °F to 104 °F |
| Installation | Indoor only |
Technical information
| Number of Channels | 8 |
|---|
Physical characteristics
| Colour | Black |
|---|
