Ajax 52251.136.BL1 Wireless Combined Heat and Smoke Detector, Replaceable Batteries, Black
About this product
The Ajax FireProtect 2 RB (Heat/Smoke) Jeweller (52251.136.BL1) is a wireless combined heat and smoke detector with replaceable batteries. It senses smoke with a double-spectrum optical sensor and dangerous temperatures with a heat sensor, sounds its in-built siren and reports alarms to the hub over Jeweller wireless communication.
Key features
- Double-spectrum optical smoke sensor that recognises smoke by the size of particles in the air
- Does not react to water vapour
- Heat alarm at temperatures above 64°C
- Temperature spike alarm when the temperature rises more than 10°C in 1 minute or less
- In-built siren: 85 dB at a distance of 3 metres
- Jeweller radio range of up to 1,700 m to a hub or range extender in an open space
- Runs on 2 × CR123A batteries with up to 7 years of battery life
- Tamper alarm if the detector is detached from the surface or the mounting panel is removed
Frequently asked questions
What batteries does the FireProtect 2 RB use?
It runs on 2 × CR123A batteries, which come pre-installed, with up to 7 years of battery life.
What is the radio range to the hub?
Up to 1,700 m between the detector and a hub (or radio signal range extender) in an open space.
How does the heat sensor decide to raise an alarm?
It alarms at temperatures above 64°C, and when the temperature rises more than 10°C in 1 minute or less. The heat sensor follows the requirements for Class A1R heat detectors (EN 54-5 and BS 5446-2).
Will steam set off the smoke sensor?
The smoke sensor does not react to water vapour.
Can it be fitted outdoors?
No. The detector is designed only for indoor installation and is rated IP20, with an operating temperature range from 0°C to +50°C.
Do several detectors sound together?
Yes. Via primary interconnection the hub initiates an interconnected alarm within 20 seconds. Fallback interconnection, where the detector alerts other detectors directly and all connected detectors activate the buzzer within a minute, works only on FireProtect 2 detectors with firmware version 5.59.2 or later, marked on the package with a “Fallback interconnect supported” label.
Specifications
Specifications
| Brand | Ajax |
|---|---|
| Model | 52251.136.BL1 |
| Manufacturer Part Number (MPN) | 52251.136.BL1 |
| Sensitive elements | smoke sensor, heat sensor |
| Smoke detection sensitive element | double-spectrum optical sensor |
| Protection from false alarms | Does not react to water vapor |
| Heat detection | Class A1R heat detector requirements (EN 54-5 and BS 5446-2) |
| High temperature alarm | at temperatures above 64°C |
| Temperature spike alarm | when the temperature rises more than 10°C in 1 minute or less |
| In-built siren | volume 85 dB at a distance of 3 meters |
| Communication | Jeweller |
| Radio frequency bands | 866.0 – 866.5 MHz, 868.0 – 868.6 MHz, 868.7 – 869.2 MHz, 905.0 – 926.5 MHz, 915.85 – 926.5 MHz, 921.0 – 922.0 MHz (depends on the region of sale) |
| Maximum effective radiated power (ERP) | up to 20 mW |
| Radio signal modulation | GFSK |
| Radio communication range | up to 1,700 m (between the detector and a hub or radio signal range extender, in an open space) |
| Detection of communication failure | within 15 minutes (depends on settings; polling interval fixed at 300 seconds) |
| Protection against spoofing | device authentication |
| Power supply | 2 × CR123A battery |
| Battery life | Up to 7 years |
| Dimensions | 124 × 124 × 45 mm |
| Weight | 272 g |
| Operating temperature range | from 0°C to +50°C |
| Operating humidity | up to 80% |
| Protection class | IP20 |
| Complete set | FireProtect 2 RB (Heat/Smoke) Jeweller, SmartBracket mounting panel, installation kit, 2 × CR123A battery (pre-installed), quick start guide |
| Colour | Black |
