All-Rack CAB6WB550BLK Wall Mounted Cabinet, 6U, 550 mm Depth
Free Delivery
£
154
56
(Incl. VAT)
RRP: £185.47
About this product
The All-Rack CAB6WB550BLK is a 6U wall mounted cabinet, 565 mm wide and 550 mm deep, compatible with 19" rack mountable products. It has a toughened glass front door, top & bottom cable entry and a loading capacity of 40 kg.
Key features
- 6U size: 565 mm wide, 310 mm high and 550 mm deep
- Compatible with 19" rack mountable products
- Toughened glass front door with a barrel lock system
- Removable and lockable side panels with barrel lock and sliding spring latch mechanism
- Top & bottom cable entry plus rear plastic cable entry
- Numbered and adjustable mounting profiles with integral cable management
- Earthing terminals and added ventilation around the cabinet
- Loading capacity 40 kg
Frequently asked questions
How big is the CAB6WB550BLK?
It is 6U, 565 mm wide, 310 mm high and 550 mm deep.
How much weight can it hold?
Its loading capacity is 40 kg. The cabinet itself has a net weight of 14.5kg.
Can the front door be hung on either side?
Yes. The front door can be mounted on the left or right hand side.
What fixings do the mounting profiles take?
The numbered uprights use standard M6 cage nuts.
Can it stand on a surface instead of being wall mounted?
The base has grommets that avoid direct contact with an abrasive surface if the cabinet is not wall mounted.
£
154
56
RRP: £185.47
Save £30.91
Price
Technical Details
Specifications
Brand
All-Rack
Model
CAB6WB550BLK
Manufacturer Part Number (MPN)
CAB6WB550BLK
Size
6U
Width
565 mm
Height
310 mm
Depth
550 mm
Material
Steel Construction
Main body
1 mm
Side panels
1.2 mm
Front door
1.2mm
Vertical rails
1.5 mm
Finish Surface
Powder Coating
Color Code
RAL9005
Loading Capacity
40 kg
Net weight
14.5kg
Gross weight
15kg
Mounting standard
IEC 297-1, 19" Mounting Standard
Specifications
| Brand | All-Rack |
|---|---|
| Model | CAB6WB550BLK |
| Manufacturer Part Number (MPN) | CAB6WB550BLK |
| Size | 6U |
| Width | 565 mm |
| Height | 310 mm |
| Depth | 550 mm |
| Material | Steel Construction |
| Main body | 1 mm |
| Side panels | 1.2 mm |
| Front door | 1.2mm |
| Vertical rails | 1.5 mm |
| Finish Surface | Powder Coating |
| Color Code | RAL9005 |
| Loading Capacity | 40 kg |
| Net weight | 14.5kg |
| Gross weight | 15kg |
| Mounting standard | IEC 297-1, 19" Mounting Standard |
All-Rack CAB6WB550BLK Wall Mounted Cabinet, 6U, 550 mm Depth
