Altronix EFLOW6NA8DV access power controller
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Altronix EFLOW6NA8DV is an access power controller.
eFlow6NA8DV distributes and switches power to access control systems and accessories. It converts a 220VAC 50/60Hz input into 8-independently controlled 12VDC or 24VDC PTC-protected outputs. These power outputs can be converted to dry form "C" contacts.
Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. Unit will route power to a variety of access control hardware devices, including Mag Locks, Electric Strikes, Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and / or Fail-Secure modes.
The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the 8-outputs.
Key features
- 8-Independently controlled 12VDC or 24VDC PTC protected outputs
- Outputs can be converted to dry form "C" contacts
- Outputs activated by open collector sink or normally open (NO) dry trigger input
- Outputs operate in Fail-Safe and / or Fail-Secure modes
- FACP Interface for Emergency Egress, Alarm Monitoring, or auxiliary devices
- Fire alarm disconnect feature individually selectable for any or all 8 outputs
- Over Voltage protection
- Short circuit and thermal overload protection
- AC fail supervision (form "C" contacts)
- Battery fail and presence supervision (form "C" contacts)
If you are matching this to an existing installation, work from the EFLOW6NA8DV part number rather than the description.
Specifications
General information
Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | EFLOW6NA8DV |
General information
| Sector | Access Control |
|---|
