Aperta A1IPKB IP PoE Single Way Kit Black
About this product
The Aperta A1IPKB is an IP PoE Single Way Kit Black. Featuring a black finish and PoE power, it is built for dependable professional installation.
Key Features
- Simple IP PoE installation
- Built-in Keypad & Fob reader for unlocking door
- Audio message alerts user if the door has been unlocked
- 10 x 13.56MHz Fobs included
- A black finish
In Detail
ESP's door entry system equipment lets occupants see and control who reaches the door, a practical security and convenience upgrade for homes, offices and communal entrances.
Designed for simple two-core or IP installation, the range is straightforward to commission and expand, with consistent ESP componentry that works together reliably.
The Aperta A1IPKB is a practical choice wherever a reliable door entry system is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | Aperta |
| Product code | A1IPKB |
| Proximity Reader | 1 |
| Dimensions (mm) | 150 x 84 x 33 |
| Finish | Gloss Black |
| Mounting | Surface & Flush |
| Materials | Polycarbonate & Aluminium |
| Operating Voltage (V DC) | 15 |
| Power Consumption (mA) | 150 |
| Secondary Power Source | PoE 802.3af/at |
| Viewing Angle (°) | 110 |
| Screen Size (Inches) | 7 (TFT LCD) |
| Video Compression | H.264 |
| Resolution | 1024 x 600 |
| Storage Device | Micro SD Card (32GB Max.) |
| User Interaction | Keypad |
| PIN Length | 6 |
| Call Duration (Sec) | 120 |
| Operating Temperature (°C) | -10 to +50 |
| Lock output | 12VDC, NO & NC Contacts |
| Relative Humidity Resistance (%) | 90 |
| Component 3 | Quantity |
| 4 Channel PoE Swich | 1 |
| Status Indication | LED indicators; PWR (Green), |
| Rate (Mbps) | 0.98 |
| PoE Power Source | 30W per Port, 802.3af/at |
| Modes Available | Extend & VLAN |
| Warranty Years | 2 |
| Weight | 2.78 kg |
| GTIN | 5060654466640 |
| Commodity Code | 8517180000 |
