Axis Communications M4338-PLVE 12 MP AI-Powered Panoramic Dome Fisheye Camera, 360° View, 03131-001
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The AXIS M4338-PLVE Panoramic Camera (part number 03131-001) is a 12 MP fisheye camera from the Axis M43 Series with a 360° view, 180°/360° coverage and a resolution of 3536x3536. It is outdoor-ready and AI-powered, with built-in IR.
Key features
- 12 MP resolution (3536x3536) on a 1/1.6" progressive scan RGB CMOS sensor
- 1.7 mm, F2.0 lens with a 185° horizontal and 185° vertical field of view; 180° or 360° coverage with no blind spots
- 12 MP at 25/30 fps in 25/30 mode; 8 MP (2880x2880) at 50/60 fps in 50/60 mode with WDR off
- Camera-side dewarped views: up to four digital PTZ views, plus panoramic, quad, corner and corridor views
- OptimizedIR with 850 nm IR LEDs (range of reach 20 m or more depending on the scene) and Forensic WDR up to 120 dB depending on scene
- AXIS Object Analytics for humans and vehicles (cars, buses, trucks, bikes, other), with up to 10 scenarios
- IP66-, NEMA 4X- and IK10-rated casing; operating temperature -40 °C to 50 °C
Frequently asked questions
What resolution does the AXIS M4338-PLVE record?
12 MP: the resolution is 3536x3536 at 25/30 fps in 25/30 mode. In 50/60 mode with WDR off it runs at 8 MP (2880x2880) at 50/60 fps.
How wide is its view?
The 1.7 mm fisheye lens has a 185° horizontal and 185° vertical field of view, and the camera offers complete 180° or 360° coverage with no blind spots.
Does it see in the dark?
Minimum illumination is 0 lux with IR illumination on. The built-in OptimizedIR uses 850 nm IR LEDs with a range of reach of 20 m or more depending on the scene.
How is it powered?
By Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4: max 16.7 W, typical 7.1 W with the heater and IR off.
Can it be installed outdoors?
It is outdoor-ready, with an IP66-, NEMA 4X- and IK10-rated casing and an operating temperature of -40 °C to 50 °C.
What is in the box?
The camera, installation guide, terminal block connector, connector guard, cable gaskets, cable hole lid and owner authentication key.
-
Download
- M4338-PLVE Tech Sheet
Specifications
Specifications
| Brand Name | Axis Communications |
|---|---|
| Manufacturer Part Number | 03131-001 |
| Product Series | M43 |
| Image Sensor | 1/1.6" progressive scan RGB CMOS, pixel size 2.0 µm |
| Lens | 1.7 mm, F2.0; fixed iris, IR corrected |
| Field of View | 185° horizontal, 185° vertical |
| Max Resolution | 3536x3536 |
| Frame Rate | 12 MP 25/30 mode: 25/30 fps (50/60 Hz); 8 MP (2880x2880) 50/60 mode (WDR off): 50/60 fps (50/60 Hz); 12 MP multi stream: 20/20 fps with 360 overview and 4 dewarped streams |
| Minimum Illumination | Colour 0.08 lux at 50 IRE, F2.0; B/W 0 lux at 50 IRE, F2.0; 0 lux with IR illumination on |
| WDR | Forensic WDR, up to 120 dB depending on scene |
| Video Compression | H.264 (Baseline, Main and High Profiles), H.265 (Main Profile), AV1, Motion JPEG |
| System on Chip | ARTPEC-9; 4 GB RAM, 8 GB Flash; deep learning processing unit (DLPU) |
| IR Illumination | OptimizedIR, 850 nm IR LEDs; range of reach 20 m or more depending on the scene |
| Power | PoE IEEE 802.3at Type 2 Class 4; max 16.7 W; typical 7.1 W (heater off, IR off) |
| I/O | 1 digital/supervised input and 1 output (12 VDC output, max load 25 mA) |
| Storage | microSD/microSDHC/microSDXC card; recording to network-attached storage (NAS) |
| Casing | IP66-, NEMA 4X- and IK10-rated; polycarbonate hard-coated dome; aluminium; white NCS S 1002-B |
| Operating Temperature | -40 °C to 50 °C |
| Operating Humidity | 10–100% RH (condensing) |
| Weight | 858 g |
| Analytics Included | AXIS Object Analytics, AXIS Image Health Analytics, AXIS Scene Metadata, AXIS Video Motion Detection |
| Audio | Input and output through portcast technology accessories or edge-to-edge pairing |
