Axis Communications 03276-001 IP dome camera
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The AXIS M3098-LV Dome Camera (Axis part number 03276-001) is an AI-powered 8 MP mini dome with IR from the Axis M30 Series. It has a 1/1.8” sensor, a 3.76 mm F2.0 lens with a 124° horizontal field of view, OptimizedIR with 850 nm IR LEDs, and an acoustic sensor with AXIS Audio Analytics.
Key features
- 8 MP: up to 12/15 fps (50/60 Hz) in 8 MP mode and up to 25/30 fps (50/60 Hz) in 4 MP mode
- 3.76 mm, F2.0 lens: 124° horizontal and 66° vertical field of view
- Built-in IR (OptimizedIR, 850 nm IR LEDs) for surveillance in total darkness; 0 lux with IR illumination on
- Forensic WDR up to 120 dB depending on scene
- AXIS Object Analytics (humans and vehicles) and AXIS Audio Analytics with a built-in acoustic sensor
- Wall and ceiling installation; the casing snaps on with no screws required
- IP42- and IK08-rated, polycarbonate hard-coated dome, white NCS S 1002-B
- PoE (IEEE 802.3af/802.3at Type 1 Class 3), max 5.9 W
Frequently asked questions
Does it have built-in IR?
Yes: OptimizedIR with power-efficient, long-life 850 nm IR LEDs, which enables surveillance in total darkness.
What is the field of view?
124° horizontal and 66° vertical, from a 3.76 mm, F2.0 lens.
Does it detect sounds?
Yes: it has an acoustic sensor, and AXIS Audio Analytics is included, with audio classes for coughing fit, glass break, human presence, scream, shout and speech.
What operating temperature is it rated for?
0 °C to 45 °C, at 10–85% RH (non-condensing).
How is it powered?
By PoE, IEEE 802.3af/802.3at Type 1 Class 3, max 5.9 W.
Which optional mounting accessories does it take?
The optional mounting accessories are the AXIS TM3401 Grid Ceiling Mount, the AXIS TM3101 Pendant Wall Mount, AXIS T91 Mounting Accessories and AXIS T94 Mounting Accessories.
-
Download
- M3098-LV Tech Sheet
Specifications
Specifications
| Brand Name | Axis Communications |
|---|---|
| Manufacturer Part Number | 03276-001 |
| Product Series | M30 |
| Product Type | Dome Camera |
| Model | AXIS M3098-LV |
| Image Sensor | 1/1.8” progressive scan RGB CMOS |
| Lens | 3.76 mm, F2.0 |
| Horizontal Field of View | 124° |
| Vertical Field of View | 66° |
| Max Resolution | 3840x2160 |
| Minimum Illumination | Colour 0.19 lux, B/W 0.05 lux (50 IRE, F2.0); 0 lux with IR illumination on |
| IR Illumination | OptimizedIR, 850 nm IR LEDs |
| WDR | Forensic WDR, up to 120 dB depending on scene |
| Casing | IP42- and IK08-rated; polycarbonate hard-coated dome |
| Colour | White NCS S 1002-B |
| Operating Temperature | 0 °C to 45 °C |
| Power | PoE IEEE 802.3af/802.3at Type 1 Class 3, max 5.9 W, typical (heater off, IR off) 3.4 W |
| Weight | 206 g |
