Axis Communications 03295-001 IP dome camera
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The AXIS P3407-VE Dome Camera (Axis part number 03295-001) is an outdoor 5 MP AI-powered PTRZ dome from the Axis P34 Series, built on ARTPEC-9. Remote PTRZ (pan-tilt-roll-zoom) allows hassle-free installation, and with PoE out it can power another device.
Key features
- 5 MP, up to 25/30 fps (50/60 Hz) in all resolutions
- Varifocal 3.0–8.5 mm, F1.38–2.58 lens: 104°-34° horizontal field of view
- Remote PTRZ (pan-tilt-roll-zoom); pan ±180°, tilt -40 to +75°, rotation ±95°
- PoE out (IEEE 802.3af/802.3bt Type 1 Class 3) to power another device
- AXIS Object Analytics (humans and vehicles) and AXIS Audio Analytics with a built-in acoustic sensor
- IP66-, NEMA 4X- and IK10-rated; operating temperature -40 °C to 50 °C
- Forensic WDR up to 120 dB depending on scene; electronic image stabilisation
- Axis Edge Vault with FIPS 140-3 Level 3 certified secure key storage and operations
Frequently asked questions
Can the view be adjusted remotely?
Yes: remote PTRZ (pan-tilt-roll-zoom) allows hassle-free installation, with pan ±180°, tilt -40 to +75° and rotation ±95°. PTR functionality has a minimum temperature of -20 °C, after 2 hours of warm-up.
Can it power another device?
Yes: it has a PoE out port (IEEE 802.3af/802.3bt Type 1 Class 3) and can be used to power another device.
What PoE does it need?
PoE input is IEEE 802.3at/802.3bt Type 2 Class 4; power consumption is max 12.95 W.
What are its environmental ratings?
IP66, NEMA 4X and IK10, with an operating temperature of -40 °C to 50 °C.
What analytics come with it?
AXIS Object Analytics, AXIS Image Health Analytics, AXIS Audio Analytics and AXIS Scene Metadata are included.
What is in the box?
The camera, installation guide, connector guard, cable gaskets and an owner authentication key.
-
Download
- P3407-VE Tech Sheet
Specifications
Specifications
| Brand Name | Axis Communications |
|---|---|
| Manufacturer Part Number | 03295-001 |
| Product Series | P34 |
| Product Type | Dome Camera |
| Model | AXIS P3407-VE |
| Image Sensor | 1/2.8” progressive scan RGB CMOS |
| Lens | Varifocal, 3.0–8.5 mm, F1.38–2.58 |
| Horizontal Field of View | 104°-34° |
| Vertical Field of View | 76°-26° |
| Max Resolution | 2592x1944 |
| Frame Rate | Up to 25/30 fps (50/60 Hz) in all resolutions |
| Minimum Illumination | 0.1 lux in colour and 0.03 lux in black and white (at 50 IRE, F1.38) |
| WDR | Forensic WDR, up to 120 dB depending on scene |
| Casing | IP66-, NEMA 4X- and IK10-rated; plastic casing, polycarbonate hard-coated dome |
| Colour | White NCS S 1002-B |
| Operating Temperature | -40 °C to 50 °C; PTR functionality from -20 °C after 2 hours of warm-up |
| PoE Input | IEEE 802.3at/802.3bt Type 2 Class 4 |
| PoE Output | IEEE 802.3af/802.3bt Type 1 Class 3 |
| Power Consumption | Max 12.95 W, typical (heater off) 5.3 W |
| Weight | 1200 g |
