Comelit PAC 1622VC entry audio unit, Module
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Comelit PAC 1622VC is an entry audio unit from the IKALL range.
Module which allows modulation and transmission of the colour video signal on the riser. On input it has the composite video signal of a colour camera. Complete with microprocessor and DIP SWITCH with 8 positions for programming calls to users.
33Vdc power supply via special power supply unit Art. 1595. On-board electronic lock-release function (3A), plus C, NC, NO contacts for 10A relay.
For use in modules Art. 33400, 33401 and 33402. Dimensions: 102x55x38 mm.
Compatible with all Simplebus 2 functions and products. It allows call addressing for up to 120000 users. Timed lock-release inputs and door open indication.
Key features
- On-board electronic lock-release function (3A), plus C, NC, NO contacts for 10A relay.
- Compatible with all Simplebus 2 functions and products.
If you are matching this to an existing installation, work from the 1622VC part number rather than the description.
-
Download
- 1622VC — User Manual
Specifications
Technical information
Physical characteristics
Miscellaneous
Attributes
Specifications
| Brand Name | Comelit PAC |
|---|---|
| Manufacturer Part Number | 1622VC |
| Product Series | IKALL |
| Product Type | Audio Module |
Technical information
| Device Supported | Door Entry Panel |
|---|
Physical characteristics
| Colour | White |
|---|---|
| Depth | 55.00mm |
| Form Factor | Module |
| Height | 38.00mm |
| Material | ABS |
| Width | 102.00mm |
Miscellaneous
| Compatibility | Comelit Ikall Entrance Panel |
|---|
Attributes
| Compatibility | Comelit Ikall Entrance Panel |
|---|---|
| Device Supported | Door Entry Panel |
