Comnet FVR10D1ES encoded video receiver, Rack Mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Comnet FVR10D1ES is an encoded video receiver from the FVT/FVR10D1E(M,S) range.
The Comnet FVT/FVR10D1E series video transmitter/receiver and data transceiver supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digital video with one bi-directional data channel plus one 10/100 Mbps fast Ethernet port. The modules are universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from most major manufacturers.
Packaged in the exclusive Comnet ComFit housing, the FVT/ FVR10D1E units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of Comnet model DINBKT1 adaptor plate.
Key features
- IEEE 802.3 Compliant
- Automatic resettable fuses on all power lines
- Status indicating LEDs provide rapid indication of critical operating parameters
- One bi-directional data channel
- One 10/100 BASE-T/TX fast Ethernet port
- Circuit boards are conformally coated to extend humidity tolerance to condensation conditions
- ComFit standard form factor is interchangeable between stand-alone or rack mount use
- Compatible with NTSC, PAL, or SECAM Video Standards
- Standard ComFit models are hot-swappable
- Electric Port Supports Auto-negotiation for Full Duplex or Half Duplex Data Throughput
If you are matching this to an existing installation, work from the FVR10D1ES part number rather than the description.
-
Download
- FVR10D1ES — Product Manual
Specifications
Technical information
Interfaces/ports
Media & performance
Network & communication
Physical characteristics
Product information
Attributes
Specifications
| Brand Name | Comnet |
|---|---|
| Manufacturer Part Number | FVR10D1ES |
| Product Series | FVT/FVR10D1E(M,S) |
| Product Type | Video Extender Receiver |
Technical information
| Media Type Supported | Fiber Optic |
|---|
Interfaces/ports
| Network (RJ-45) | Yes |
|---|---|
| Number of Network (RJ-45) Ports | 1 |
| Number of ST Ports | 1 |
Media & performance
| Network Technology | 100Base-TX, 10Base-T |
|---|
Network & communication
| Ethernet Technology | 100 Mbps (Fast Ethernet) |
|---|
Physical characteristics
| Depth | 27.94mm |
|---|---|
| Height | 27.94mm |
| Width | 134.62mm |
Product information
| Mount Type | Rack Mount |
|---|
Attributes
| Environmental status | Yes |
|---|
