Cranford Controls 510-059 siren, White
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Cranford Controls 510-059 is a siren from the VTG range.
The VTG family of sounders have been designed to cover a wide spectrum of applications. The 12 volt version has been designed for general use and is particularly suited to security signalling applications. The sounder as standard comes with 32 tones.
The product is supplied with a two-stage alarm override which is activated by a third negative wire if required. All tones have been selected to comply with the latest sound patterns and frequencies used throughout the world. All tone options are fully synchronised.
The anti-tamper version is fitted with an integrated switch and when configured on installation means that unauthorised removal of the sounder will result in the automatic reporting of the event to the control panel
Key features
- 32 tones plus a selectable override tone
- Anti-tamper version available
- Shallow base IP43 and deep base IP65 versions available
- Unique twist and lock bayonet mounting system
- Removable cover on deep base for surface wiring
- Features base locking system as standard
If you are matching this to an existing installation, work from the 510-059 part number rather than the description.
Specifications
General information
Technical information
Environmental conditions
Physical characteristics
Power description
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | Cranford Controls |
|---|---|
| Manufacturer Part Number | 510-059 |
| Product Series | VTG |
| Product Type | Siren |
General information
| Application/Usage | Fire Alarm |
|---|
Technical information
| Alarm Type | Audible |
|---|
Environmental conditions
| Sound Emission | 101dB |
|---|
Physical characteristics
| Colour | White |
|---|---|
| Height | 85.00mm |
Power description
| Input Voltage | 15V DC |
|---|
Product information
| Diameter | 93.60mm |
|---|---|
| Shape | Round |
Miscellaneous
| Indoor or outdoor use | Indoor |
|---|
Attributes
| Input Voltage | 15V DC |
|---|
