Dahua Technology DHI-VTO4202F-P1 apartment door station, 2MP
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Dahua Technology DHI-VTO4202F-P1 is an apartment door station from the Pro range.
The Dahua DHI-VTO4202F-P1 is a modular IP apartment door station designed for video intercom applications, featuring a 2MP HD CMOS low illumination camera with a wide 168.6° field of view for colorful imaging. It includes an anodized aluminum front panel for durability and supports both surface and flush mounting options in silver finish. Certified with IK07 and IP65 ratings, this device ensures robust performance against impact and environmental factors.
It supports video compression standards H.265 and H.264 and provides a 12VDC 600mA power supply, with PoE compatibility requiring connection to a PSE switch adhering to the 802.3.at standard. Remote communication and access control are enabled via a mobile phone app, allowing users to talk to visitors and unlock the door remotely.
Key features
- Anodized aluminum front panel
- CMOS low illumination 2MP HD colorful 168.6° camera
- Video intercom function
- Provides 12VDC 600mA power
- Mobile phone app talk to the visitor or unlock the door remotely on your phone
- IK07 and IP65 rated
- Support surface and flush mount
- Support H.265 and H.264
- Standard PoE power supply (if the VTO device with 12V power output needs to charge the load it should be connected to a PSE switch that complies with the 802.3.at standard)
If you are matching this to an existing installation, work from the DHI-VTO4202F-P1 part number rather than the description.
Specifications
Technical information
Physical characteristics
Video
Specifications
| Brand Name | Dahua Technology |
|---|---|
| Manufacturer Part Number | DHI-VTO4202F-P1 |
| Product Series | Pro |
Technical information
| Effective resolution | 2MP |
|---|
Physical characteristics
| Form Factor | Door |
|---|
Video
| Maximum Resolution | 1920 x 1080 |
|---|
