Dahua Technology PFS3006-4ET-36 ethernet switch
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Dahua Technology PFS3006-4ET-36 is an ethernet switch.
Unmanaged industrial switch equipped with 2 uplink ports (10/100 Mbps) and 4 10/100 Mbps PoE ports, the total power budget for PoE is 36W.
Key features
- Support four 10/100M PoE power supply ports, and two 10/100M uplink ports
- Support 802.3af and 802.3at standards
- OperatingTemperature: -10°C to +55°C
- Support 250 m long distance PoE tansmission
- Support PoE watchdog
If you are matching this to an existing installation, work from the PFS3006-4ET-36 part number rather than the description.
Specifications
Certifications
Interfaces/ports
Media & performance
Physical characteristics
Power description
Attributes
Specifications
| Brand Name | Dahua Technology |
|---|---|
| Manufacturer Part Number | PFS3006-4ET-36 |
| Product Type | Ethernet Switch |
Certifications
| RoHS compliance | Compliant |
|---|---|
| WEEE Compliant | Compliant |
Interfaces/ports
| Total Number of Network Ports | 6 |
|---|
Media & performance
| Network Technology | 100Base-TX |
|---|
Physical characteristics
| Depth | 108.10mm |
|---|---|
| Height | 35.00mm |
| Width | 194.00mm |
Power description
| Power Source | AC Power |
|---|
Attributes
| Power Source | AC Power |
|---|
