Dahua Technology DH-PFS3409-4GT-96 unmanaged desktop switch, Desktop Mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Dahua Technology DH-PFS3409-4GT-96 is an unmanaged desktop switch.
DH-PFS3409-4GT-96 is an unmanaged Hardened PoE Switch with 4 x 10/100/1000 Mbps PoE Ports. It provides 4 x 10/100/1000 Mbps Ethernet ports , 4 x 1000 Mbps SFPs and 1 x 10/100/1000 Mbps Ethernet uplink ports . The product is equipped with two types of transmission modes (Extend Mode On/Extend Mode Off).
It also supports PoE watchdog to avoid manually maintenance and device restart, which can realize the intelligent management and reduce the cost.
Key features
- Provides control over power consumption and offers real-time monitoring to ensure power supplies receive priority with important ports and to prevent malfunctions caused by changes in power consumption
- The red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoE standards, with a maximum output power consumption rate of 90 W per port
- Adopts the innovative PoE Watchdog. PoE Watchdog can be switched on by dialing or turning on the WEB page switch
Technical Details
Specifications
Brand Name
Dahua Technology
Manufacturer Part Number
DH-PFS3409-4GT-96
Product Type
Switch
Technical information
Power Consumption
96.0000W
I/o expansions
Number of SFP Slots
4
Number of Total Expansion Slots
4
Interfaces/ports
Network (RJ-45)
Yes
Total Number of Network Ports
15
Uplink Port
Yes
Management & protocols
Manageable
No
Network & communication
Ethernet Technology
1 Gbps (Gigabit Ethernet)
Networking Standards
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Physical characteristics
Height
110.00mm
Width
150.00mm
Power description
Input Voltage
48-57V DC
PoE (RJ-45) Port
Yes
PoE Budget
120W
Power Source
DC Power, PoE (Power over Ethernet)
Product information
Length
150.00mm
Mount Type
Desktop Mount
Attributes
Input Voltage
48-57V DC
Power Source
DC Power, PoE (Power over Ethernet)
Specifications
| Brand Name | Dahua Technology |
|---|---|
| Manufacturer Part Number | DH-PFS3409-4GT-96 |
| Product Type | Switch |
Technical information
| Power Consumption | 96.0000W |
|---|
I/o expansions
| Number of SFP Slots | 4 |
|---|---|
| Number of Total Expansion Slots | 4 |
Interfaces/ports
| Network (RJ-45) | Yes |
|---|---|
| Total Number of Network Ports | 15 |
| Uplink Port | Yes |
Management & protocols
| Manageable | No |
|---|
Network & communication
| Ethernet Technology | 1 Gbps (Gigabit Ethernet) |
|---|---|
| Networking Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
Physical characteristics
| Height | 110.00mm |
|---|---|
| Width | 150.00mm |
Power description
| Input Voltage | 48-57V DC |
|---|---|
| PoE (RJ-45) Port | Yes |
| PoE Budget | 120W |
| Power Source | DC Power, PoE (Power over Ethernet) |
Product information
| Length | 150.00mm |
|---|---|
| Mount Type | Desktop Mount |
Attributes
| Input Voltage | 48-57V DC |
|---|---|
| Power Source | DC Power, PoE (Power over Ethernet) |
