Eaton TB16-RS emergency call station
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Eaton TB16-RS is an emergency call station.
Eaton VoCALL 16 is a high specification, digital, loop driven, intelligent emergency voice communication system offering sophisticated functionality along with simple and intuitive end user interface. VoCALL16 is designed to ensure the simplicity of future system expansion without additional accessories. A maximum of 16 outstations of any combination can be connected to a main panel on the loop.
Loop wired confi guration along with short circuit isolators ensures the network is fault tolerant. The system uses digital audio communication to achieve high audio quality and intelligibility when it matters the most. Continuous fault monitoring ensures high availability.
Extensive time stamped logs, also available on SD cards, ensures ease of debugging. The simplicity of operation, ease of cabling and competitive pricing make the system suitable for a wide range of applications. In combination with our range of soft addressable digital outstations, stand-alone system reduces labor and material cost along with potential for wiring errors associated with traditional spur systems.
Key features
- Up to 16 digital outstations per panel
- 4 core loop configuration
- Soft addressing of outstations
- Extensive time stamped logs on SD card
- Large graphical user interface
- PIN protected user access
- Flush mount options
- Fully compliant with BS5839-9
If you are matching this to an existing installation, work from the TB16-RS part number rather than the description.
Specifications
Specifications
| Brand Name | Eaton |
|---|---|
| Manufacturer Part Number | TB16-RS |
Eaton TB16-RS emergency call station
