Elmdene by Potter VS303 high security contact, Silver
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Elmdene by Potter VS303 is a high security contact.
Surface - High Security Contact - Grade 3 - Large heavy duty - Anodised Aluminium. Triple Biased with Active tamper. 5mm operating gap.
Includes security cover plate. 109L x38w x19D. The VS303 sensor, magnet and cover are supplied as a matched set.
Do not attempt to use the sensor with any other magnet except as supplied or you may experience incompatibility problems. Mount the magnet to the opening fixture and fix the cover with the screws provided so the magnet fixings are not visible and the black spot on the underside of the cover is still visible. Fix the sensor such that when the door is closed, all the fixing screws are covered and the dots on the magnet and sensor are aligned.
Ideally the gap between sensor and magnet should be no more than 5mm.
Key features
- Triple Biased with Active tamper
- 5mm operating gap
- Ideal for single or multiple doors
- Detection of magnetic field interference
- Includes security cover plate
- IP67 rated
- Suitable for use in systems designed to comply with PD6662:2017
If you are matching this to an existing installation, work from the VS303 part number rather than the description.
Specifications
Technical information
Certifications
Physical characteristics
Product information
Specifications
| Brand Name | Elmdene by Potter |
|---|---|
| Manufacturer Part Number | VS303 |
Technical information
| Connectivity Technology | Wired |
|---|
Certifications
| Security Grade | Grade 3 |
|---|
Physical characteristics
| Colour | Silver |
|---|---|
| Material | Aluminium |
Product information
| Mount Type | Surface Mount |
|---|
Elmdene by Potter VS303 high security contact, Silver
