Elmdene by Potter STX2410-MOD power supply, Unboxed

Free Delivery
£ 263 10
(Incl. VAT)

About this product

Please note: this is a non-returnable item (excluding faulty goods)

Elmdene by Potter STX2410-MOD is a power supply from the STX range.

The STX2410-MOD is an EN54-4:1997 +A1 +A2 approved power supply ideal for use in Fire and Smoke and ventilation control Systems. Its regulated 27.6V dc output will supply up to 2 Amps continuous into the load, in addition to providing up to 700 mA for charging the standby batteries up to 18 Ah. The power supply output features electronic short circuit protection under both mains and standby battery operation.

Maximum battery life is assured through continuous active battery monitoring and the use of a two stage charger, comprising bulk and temperature compensated final float phase depending upon battery condition. Once fully charged the product operates in Eco power saving mode, whereby the batteries are charged for 4 hours in every 24 hour period while still being continuously monitored. This reduces wasted energy in charging already fully charged batteries and extends their working life.

Deep discharge protection prevents premature battery failure when operating from standby for extended periods. Two sets of volt free solid state relay fault output signal (i) loss of mains and (ii) battery fault, charger fault and loss of output. In addition there is an optional plug in serial interface that can provide diagnostic and fault reporting information to supervisory systems.

Key features

  • Intelligent Battery charging
  • Mains & Battery monitoring with independent volt free fault outputs

If you are matching this to an existing installation, work from the STX2410-MOD part number rather than the description.

£ 263 10
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£263.10 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Info about this product
Technical Details
Specifications
Brand Name
Elmdene by Potter
Manufacturer Part Number
STX2410-MOD
Product Series
STX
Product Type
Power Supply
Technical information
Output Voltage
27.6V DC
Certifications
Certifications & Standards
A1:2002 & A2:2006, EN54-4:1997
Physical characteristics
Form Factor
Unboxed
Power description
Input Voltage
240V AC
Output Current
10.0000A
Attributes
Environmental status
Yes
Input Voltage
240V AC
Output Current
10.0000A
Output Voltage
27.6V DC
Specifications
Technical information
Certifications
Physical characteristics
Power description
Attributes

Specifications

Brand Name Elmdene by Potter
Manufacturer Part Number STX2410-MOD
Product Series STX
Product Type Power Supply

Technical information

Output Voltage 27.6V DC

Certifications

Certifications & Standards A1:2002 & A2:2006, EN54-4:1997

Physical characteristics

Form Factor Unboxed

Power description

Input Voltage 240V AC
Output Current 10.0000A

Attributes

Environmental status Yes
Input Voltage 240V AC
Output Current 10.0000A
Output Voltage 27.6V DC

Elmdene by Potter STX2410-MOD power supply

Elmdene by Potter STX2410-MOD power supply, Unboxed

Who this is for

For the installer — this is the power supply supplied under Elmdene by Potter part number STX2410-MOD. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is a power supply made by Elmdene by Potter. The part number STX2410-MOD is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this power supply is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is non-returnable, excluding faulty goods. That restriction comes from the manufacturer's own terms for this line.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact power supply I have been quoted? Check the manufacturer part number STX2410-MOD against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Yes — a document attached to this listing was checked and names this exact part number.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against STX2410-MOD answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.

Elmdene by Potter STX2410-MOD power supply
Elmdene

Elmdene by Potter STX2410-MOD power supply, Unboxed

£263.10

Please note: this is a non-returnable item (excluding faulty goods)

Elmdene by Potter STX2410-MOD is a power supply from the STX range.

The STX2410-MOD is an EN54-4:1997 +A1 +A2 approved power supply ideal for use in Fire and Smoke and ventilation control Systems. Its regulated 27.6V dc output will supply up to 2 Amps continuous into the load, in addition to providing up to 700 mA for charging the standby batteries up to 18 Ah. The power supply output features electronic short circuit protection under both mains and standby battery operation.

Maximum battery life is assured through continuous active battery monitoring and the use of a two stage charger, comprising bulk and temperature compensated final float phase depending upon battery condition. Once fully charged the product operates in Eco power saving mode, whereby the batteries are charged for 4 hours in every 24 hour period while still being continuously monitored. This reduces wasted energy in charging already fully charged batteries and extends their working life.

Deep discharge protection prevents premature battery failure when operating from standby for extended periods. Two sets of volt free solid state relay fault output signal (i) loss of mains and (ii) battery fault, charger fault and loss of output. In addition there is an optional plug in serial interface that can provide diagnostic and fault reporting information to supervisory systems.

Key features

If you are matching this to an existing installation, work from the STX2410-MOD part number rather than the description.
