ESP EZTAG3B Proximity and Keypad Door Entry, Black
About this product
The ESP EZTAG3B is a Proximity and Keypad Door Entry, Black. Featuring a black finish, it is built for dependable professional installation.
Key Features
- Easy install, simple self-contained programming
- Up to 1,010 key tag holders or Pin numbers
- 2 separate user groups
- 2 relay outputs
- A black finish
In Detail
ESP's access control readers equipment lets occupants see and control who reaches the door, a practical security and convenience upgrade for homes, offices and communal entrances.
Designed for simple two-core or IP installation, the range is straightforward to commission and expand, with consistent ESP componentry that works together reliably.
The ESP EZTAG3B is a practical choice wherever a reliable access control readers is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | ESP |
| Product code | EZTAG3B |
| Dimensions (mm) | 150 x 44 x 24 |
| Colour | Blue |
| Fob Reader Operating Distance (mm) | <50 |
| Materials | Aluminium |
| Mounting | Surface |
| Maximum Capacity | Zone 1; 1000 Fob/PIN |
| Backlit | Keys; Blue LEDs |
| Tamper Facility | Yes |
| Status Indication | Red, Green, and Amber LEDs |
| Supply Voltage (V AC) | 12 - 24 |
| Operating Voltage (V DC) | 12 - 24 |
| Operating Current (mA) | 110 |
| Unlatched Relay Time | 1 - 99 Seconds |
| Maximum Switchable Load | 30V @ 4A |
| Type | Latched & Unlatched |
| Lock outputs | 2 |
| PIN Length | 2 - 6 Digits |
| Relay Types | Normally Open & Normally Closed; |
| Warranty Years | 2 |
| Weight | 0.552 kg |
| GTIN | 5060654460990 |
| Commodity Code | 8537109199 |
