ESP CPS9W 9 Way 12V DC 5Amp CCTV Power Supply
£
39
88
(Incl. VAT)
2 Years Warranty
9 Way 12V DC 5Amp CCTV Power Supply
About this product
About this product
The ESP CPS9W, from ESP's CCTV range, is a 9 way 12V DC 5 Amp CCTV power supply with 9 outputs, each rated 12V DC regulated @ 1 Amp. It runs from a 110 - 240 V AC supply.
Key features
- 9 outputs, 12V DC regulated @ 1 Amp each
- 1.1A automatic PTC fuses protecting each output
- Short circuit & surge protection
- AC input & DC output LED indicators, plus individual LED indicators per output
- Internal on/off power switch
- Key lock to secure internals
- 9 x male DC plugs (2.1 x 5.5mm)
- 110 - 240 V AC supply
Frequently asked questions
How many outputs does the CPS9W have?
9, each rated 12V DC regulated @ 1 Amp.
What mains supply does it need?
110 - 240 V AC.
How are the outputs protected?
Each output has a 1.1A automatic PTC fuse, and the unit has short circuit & surge protection.
What connections does it have?
9 x male DC plugs (2.1 x 5.5mm).
Can the internals be secured?
Yes. It has a key lock to secure internals.
-
Download
- CPS9W Tech Sheet
£
39
88
FAST delivery by Order within
Price
Technical Details
Specifications
Colour
Grey
Materials
Steel
Mounting
Surface
Warranty (Years)
2
Supply Voltage (V AC)
110 - 240
Number of Outputs
9
Output Rating
12V DC Regulated @ 1 Amp (each)
Dimensions (mm)
201.5 x 238.5 x 61.5
Connections
9 x Male DC Plugs (2.1 x 5.5mm)
Specifications
| Colour | Grey |
|---|---|
| Materials | Steel |
| Mounting | Surface |
| Warranty (Years) | 2 |
| Supply Voltage (V AC) | 110 - 240 |
| Number of Outputs | 9 |
| Output Rating | 12V DC Regulated @ 1 Amp (each) |
| Dimensions (mm) | 201.5 x 238.5 x 61.5 |
| Connections | 9 x Male DC Plugs (2.1 x 5.5mm) |
9 Way 12V DC 5Amp CCTV Power Supply features
ESP CPS9W 9 Way 12V DC 5Amp CCTV Power Supply
